Model

1543 + Built-in Microphone

Camera

Image Sensor

1/3" CMOS

Effective Pixels

3072 (H) × 2048 (V)

Electronic Shutter

AUTO, 1/25s ~ 1/100000s

Min. Illumination

0.001Lux@F1.2(AGC ON), 0Lux IR on

Day/Night

Auto/Color/(B/W)/Timing

WDR

Digital WDR

White Balance

Auto/Indoor/Outdoor

BLC

Support

DNR

2D/3D DNR

Other

Motion Detection, Privacy Mask, Mirror, flip

Encode

Embedded Solution

SSC337

Video Standard

H.264/H.265

Video Resolution

Main Stream:25fps@ 6MP(3072*2048)

Sub Stream: VGA(640x480)/360P@25fps, etc.

Video Bitrates

32Kbps - 6Mbps, VBR/CBR

Audio Standard

G.711-u/G.711-a

OSD Overlay

Title and Time overlay

LedS

Leds

2PCS Soft & Warm Supplemental Light

Light Distance

25-30 M

Lens

Focal length

HD 2.8mm F1.0 true starlight lens

Optional Function

Audio

Network Services

Protocol

HTTP/RTSP/FTP/NFS/SMTP/DHCP/NTP, etc.

P2P

Yes

Web

IE , Firefox, etc.

Media

CMS, Android, IOS

ON-VIF

17.06 compatible

General

Network Port

1-RJ45, 100Mbps,

Power Supply

IEEE802.3af PoE, 12 VDC ± 10%

Power Consumption

< 8 W

Operating Temp.

-30℃-(+60)℃, 10%-90%RH
