Notice: Please double-check the OE number before purchase to ensure fitment. You may provide last 8 digits of your VIN to a local authorized dealer on your own to help confirm OE reference number, if available.

Turbo Turbocharger

Replacement for S300SX3-S366 A/R .91 T4 320-800HP Twin Scroll 177275

Specifics:
Turbine Inducer: 80mm/3.14in
Turbine Exducer: 73mm/2.9in
Turbine Trim: 85
Turbine A/R: 0.91
Turbine Wheel: 10 blades
Turbine Inlet Flange Type: T4
Turbine Outlet Flange Type: for Marmon flange

Compressor Inducer Diameter: 66mm/2.6in
Compressor Exducer: 96mm/3.8in
Compressor Trim: 47
Compressor Wheel: 7+7 blades
Horse Power: Up to 320-800hp
Scroll Type: Twin Scroll
Bearings Type: Floating bearing
Trust Bearings: 270 Degrees
Cooling Type: Oil cooling

Oil Return: 2-3/8-16
Oil Inlet: 4.8mm

Applications:

for John Deere Agricultural Tractor with 6081H 2001-06

for John Deere Various

Turbo Model:

Replacement for S300G, S300S-084, S300S0102, S300S084, S300-83H33DC-AGM/0.9176ZD3

Engine: 6081H

Replacement & Part Number：
177272, 177275, 177281,176635,176647

Note:

* Please confirm your factory-fitted turbo PART NUMBER before Purchasing
* Professional installation is highly recommended
* Before  installation, please check the oil supply sufficient, clearnliness the air filter and gasoline , and the gasoline air tightness.
