Wind Turbine Generator 3000W 48V 3 Blade Wind Power Kit with MPPT Controller

  • FEATURES:

    1.Low start up speed ,high wind energy utilization

    2.Easy installation, tube or flange connection optional

    3.Blades using new art of precision injection molding,matched with optimized aerodynamic shape and structure which enhance the wind energy utilization and annual output.

    4.Body of casting aluminum alloy, with 2 bearings swivel , making it survive stronger wind and run more safely




    5.Patented permanent magnet ac generator with special stator,effectively reduce torque,well match the wind wheel and generator, and ensure the performance of whole system.

Model ID:M5-3000

Rated power:3000W

Maximum power:3150W

Rated voltage: 48V

Start up wind speed: 3m/s

Rated wind speed:17m/s

Security wind speed:50m/s

Numbers of blades:3

Blade length:95cm
Wind wheel Diameter:195cm

Blade material:Nylon fiber

Type of generator:Three phase AC permanent Magnet Synchronous

Magnetic Steel material: NbFeB

Control system:Electromagnet

Working Temperature:-40℃-80℃

Design life:20 Years





PACKING LIST:

wind turbine 1set(hub,tail, blades,generator,hood,bolts and nuts)
installation tool 1 set.

MPPT charge controller 1 piece.
flange 1 piece.
