0.5mm Nozzle K-3 Pneumatic Spray Paint Gun Air Brush & Aluminum Swivel Cup

Features:

1. Perfect ergonomic design to reduce wrist fatigue.

2. Spray trigger: flexible operation, good atomization effect, good feel.

3. Applicable to automobile spray paint, wood spray paint, wall spray paint.

4. Made of special aluminum alloy, reducing paint adhesion in watering cans.

5. Compatible with solvent and waterborne coatings (No chemical reaction to aluminum)

6. Atomizing: improve paint efficiency, uniform and fine, copper processing, wear-resistant, durable.

7. Spray range control: spray range knob adopts special anti-skid design, with fine spray control to save paint.

8. New air cap design with increased pattern shape stability improves atomization and decreases mottling and blotching.

9. Air pressure adjustment: turn the adjusting screw clockwise to reduce the air quantity and counterclockwise, it increases.

10. Spray nozzles: made of stainless steel, hardened and wear-resistant, with longer service life and better sealing. It can be removed for cleaning and maintenance.

Specification:

Condition: 100% Brand New

Color: Silver

Model: K-3

Material: Stainless Steel+Aluminum Alloy

Spray Bottle Capacity: 125ml

Air Inlet: 1/4"

Fluid Nozzle: 0.5mm

Feeding Mode: Gravity Feeding

Application: Spaying on Cars, Furniture, Toys, Instruments and Machines

Best Spraying Distance: 100-150mm

Packing Included:

1 x Spray Gun

1 x Aluminum Cup

1 x Spanner

1 x Brush

1 x Instruction Manual

Instructions:

1. Pour the paint with good proportion into pot and connect with the feed joint.

2. Connect the compressed air to the air inlet connector.

3. Pull the trigger and adjust the proper working air pressure (3.5-4.5bar).

4. Adjust the amount of paint and spray width (adjust as needed).

5. Parallel and vertical spray on the cleaning surface (spray distance is about 20cm / 7.9in).

Difference Between Upper And Lower Pots:

1. The lower pot S is suitable for spraying horizontally or less than 45 degrees up and down.

2. The upper pot G can be rotated, suitable for 360-degree spraying.

3. The lower pot have large capacity, and the upper pot have small capacity, chosen according to the usage scenario.

Spray Gun Cleaning Method:

At the end of each day's work, clean the spray gun with water. The cleaning method is as follows: let Tianna water(Nitrocellulose lacquer thinner)or spray gun water spray out from the gun body like oil spray. Repeat the operation. After cleaning, close the paint and dry it by hanging. Every other week, the needle nozzle and atomizing cap need to be removed, then soaked in Tianna water, cleaned, dried, applied with a little pneumatic oil, and then installed into the spray gun. Note that the nozzle interface is wrapped with white sealing tape to ensure the airtightness of the spray gun. If the viscosity of high spray paint, two or three days can be operated once. If the paint is properly maintained, it will increase its service life and maximize its value.

Notes:

1. After the completion of cleaning, do not mess up the knock.

2. All dimensions are measured by hand, there may be small deviations.

3. The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness.
