only one input voltage and output voltage can be chosen!
Different dc voltage and ac voltage can be customized! Please leave me a messages of your specifications.(about input voltage,output voltage,frequency and socket type)
1.What's your input voltage?12v or 24v or 48v?
(If the input is 72v or 110v, the additional 20%
price will be needed. If you need remote controller, we need more 15
USD.Please contact with me. I'll change your price, or you can pay us by
paypal.)
2.What's your output voltage? 120v or 220v?
3.What's your frequency? 50HZ or 60HZ?
4.What's your socket type? please look at the picture I attached and make a choice.
Please leave your clear delivery information and contact number.
Application:
-Energy system: Solar energy source system, Wind energy source system, Car system, etc.
-Office Equipment: PC, Laptop, Printer,etc.
-Home Appliance: TV, Air conditioner, Oven, Cooker, DVD, GPS Fridge, Cleaner, Washer, Fan, Light, Refrigerator, etc.
-Industrial Equipment: Pump, Compressor, Motor, etc.
For resistive load applications:
If you need the inverter to run the resistive load (like laptop, TV, electric cooker,LED light), please choose the inverter with continuous power higher than the appliance's rated power.
For inductive load applications:
If you use Refrigerators, air conditioners and other appliances with compressors ,please choose the inverter whose continuous power is 3-7 times higher than your appliances.
|
DC Voltage |
12V or 24V or 48V |
|
Voltage Range |
10-15VDC or 21-30VDC or 42-60VDC |
|
NO Load Current Draw |
<0.6A |
|
Efficiency |
>85% |
|
DC Connector |
Cables With Clips or Car Adaptor |
|
AC Voltage |
120VAC or 220VAC or 240VAC |
|
Continuous Power |
500W |
|
Surge Power |
1000W |
|
Waveform |
Pure Sine Wave |
|
Frequency |
50HZ or 60HZ |
|
AC Regulation |
3% |
|
Low Voltage Alarm |
10DC±0.5V or 20.5DC±1V or 44VDC±1V |
|
Low Voltage Shut Down |
9.5DC±0.5V or 19.5DC±1V or 42VDC±1V |
|
Over Load |
Shut Off Output |
|
Over Voltage Shut Down |
15.5V or 30.5V or 61.2V |
|
Over Thermal |
Shut Off Output Automatically |
|
Fuses |
Short Circuit |
|
Working Temperature |
Between -10centi and +50centi |
|
Working Humidity |
20%~90%RH non-condensing |
|
Storage Temperature |
Between -30centi and +70centi |
|
Start |
Soft Start |
|
Cooling Ways |
Cooling Fan |
|
Total Harmonic Distortion THD |
<5% |
|
Machine Size(mm) |
260*170*85mm |
|
Net Weight(kgs) |
2.22KG |
|
Packing Type |
Carton Packing |
Product Pictures:
Product Details :
Protection Systems:
Thermal protection, Overload protection, Over Voltage protection, Under Voltage protection, Low Voltage protection alarm. Inverter comes with an LED light to indicate the problem.
9 kinds of Productions:
Short circuit production High temperature production..
High voltage protections Low voltage protections
Over current Protection Overload protection
Surge protection Fuse protection Reverse protection
The Resistive Load Applications and The Inductive Load Applications:
For resistive load applications:
If
you need the inverter to run the resistive load (like laptop, TV,
electric cooker, LED light), please choose the inverter with continuous
power higher than the appliance's rated power.For example, for the power
inverter with continuous power 2500w,it is suggested to run the
appliance with rated power less than 2500w. It is best to use 80% of the
rated power.
For inductive load applications:
If
you need the inverter to run the inductive load (for appliance such as
compressor, motor, water pump), please calculate the power of inverter 3
to 7 times higher than the rated power of your appliance.
Product Certification:
Durable
and safe quality with many years usage, our pure sine wave inverters
are approved by EMC testing in Australia and CE certified. 18 months warranty.
The Packaging:
The Transportation:
For the small capacity, The inverter will be sent by DHL, EMS, Fedex and TNT, it will take 3-9 days for shipping.
If you have any question in the transport process, please contact with me in time.
Customer Service:
-12 months warranty.
- Please leave me the message about the DC input, AC output, the frequency and the socket type before shipping, I will confirm for you. If the package is returned for customer's fault, the customer need to pay for additional fee, if not, we will pay for additional fee and send the right one at once.
- Please attention if the package is broken before you received it, please don't open the package and show me the photo, I will contact with the express at once.
- If you have any question when you use the inverter, please feel free contact with me, the professional technical department will help you to deal with the problem.
FAQ:
Q 1. what's the payment term?
A. You can make a payment online, the TT, PayPal ,Western Uninon is also accepted.
Q 2. how's the delivery time ?
A. Sample will be sent in 3 days, big order according to the quantity , 2 weeks at most.
Q 3. tell me the standard of package?
A. For the small capacity, it use carton, but for big capacity, we should use strong wooden case for protection.
Q 4. what kind of material of transformer?
A. We use 100% copper
Q 5.Could you offer Form A or C/O ?
A. Really no problem. We can prepare relative documents to forgin affairs office or other office to apply for this certificate.
Q 6.Would you accept to use our logo ?
A.If you have good quantity,absolutely no problem to do OEM.
Q 7.Could you accept the customized inverter ?
A. Yes, we accept the customizing inverter, such as print the logo in the shell, change the color of the shell.
Q 8.Where is your market?
A. We have been doing Europe, Russia , America ,Brazil ,Australia market for about 8 years , reliable quality make our business last long
Q 9.Does the inverter connect with solar/wind system ?
A.Yes. we have both off grid and on grid pure sine wave inverter
Q10. what kind of certificate you have ?
A. Our company already achieve CE , EMC certification .
PayPal is the only online payment method we accept. Please make sure you have a valid/confirmed PayPal account prior buying.
All PayPal Payments must be Confirmed (Shipping and billing addresses must match).
Payment must be made within 30 days after the purchase. Otherwise, it will open the unpaid case automatically to cancel the order and there will be unpaid record for the buyer.
We ship items free to America, Canada, United Kingdom, Australia, Europe, Asia.
The shipment is by Fedex or China EMS Service with time 3~7 working days.
All items will be shipped within 1~3 business days upon receipt of payment (except Saturday and Sunday and statutory holiday in China).
Please Note:
● Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer’s responsibility. It is normally collected by the delivering freight (shipping) company or when you pick the item up – do not confuse them for additional shipping charges and the shipping company will give you a receipt from the custom office.
● You can check it with your country’s customs office to determine what these additional costs will be prior to bidding/buying.
Warranty: 365 days
Technical support and service are provided for the inverter the whole life.
FEEDBACK
Note: Do not hesitate to contact us anytime before and after the purchases, we are committed to your 100% customer satisfaction.
I am here and ready to assist you with any question or concerns you might have before or after the purchase.
If you have the problem with the item, please contact us first with eBay message BEOFRE you open return request or file a dispute or leave the netural or negative feedback.
My goal is to make sure you are happy and having the pleasant shopping with us.
The company’s power inverters convert and control raw electrical power from any renewable or back up ower source into high quality pure sine wave power.
Our product range from off grid high frequency pure sine wave inverter (150W to 8000W) and grid tie inverter (200W to 2000W). Most of them are hot products in the market such as.
1.High frequency pure sine wave inverter up to 8000w with stable performance,with LED and LCD display;
2. High advanced LCD display 2000w grid tie inverter with 45-90vdc input., build-in dump load for small grid PV system
3. the highly compact designed micro inverter for 0.82kgs with power line carrier-current communication, it can built up a megawatt solar power station.
Our pure sine wave inverters meet the needs of a wide range of application such as for vehicle , marine, train or any mobile power station. . The special DC volt 36V, 72V ,96V, 110VDC ect can be selected for special application.
Reliable Electric is identified as one of the most famous trademarks in China for pure sine wave inverter for its relaible power inverter, reasonable price and responsible service.
Reliable electric is committed to improving the environment and the renewable energy industry and continues to develop more efficient and cost-effective solutions to bring more green electricity to our lives.
