1/2/5/10PCS SN65HVD230 CAN Bus Transceiver Communication Module For Arduino
Popular
Product Introduction
Product Description:
SN65HVD230 can be used under high interference environment.
The device has the ability to send and receive good at different rates,
and its main features are as follows:
Fully compatible with ISO11898 standard;
High input impedance, allowing 120 nodes;
Low current standby mode, the typical current of 370μA;
Signal transfer rate up to 1Mb / s;
Thermal protection, open circuit failure protection function;
With anti-instantaneous interference protection bus;
Slope control, reduce radio frequency interference (RFI);
Differential receiver with a wide range of anti-common-mode interference,
electromagnetic interference (EMI) capabilities.
Operating modes and control logic
SN65HVD230 high speed, slope and wait three different modes of operation.
Its working mode control can be achieved by the control pin Rs.
Figure 2 is a SN65HVD230 CAN bus system in a typical application diagram.
Can be seen from the figure, CAN controller is connected
to the output pin Tx SN65HVD230 data input terminal D,
this data can be transferred to the CAN node sends CAN network;
CAN controller and receive pins of Rx and SN65HVD230 R is connected to
the data output terminal, for receiving data.
Select the port Rs SN65HVD230 way via jumpers and end of
the ground slope resistor can be achieved through hardware
mode select three modes of operation, in which
the slope is 0 ~ 100kΩ resistor potentiometer
Package Included:
- 1/2/5PCS x SN65HVD230 CAN bus transceiver communication module For Arduino
- We accept PayPal only. But we only Accept your Ebay Address,Please Make sure it's 100% right.
- Payment must be received in 5 business days of auction closing.
- Please leave note for your special request (e.g. Colors or Size) in PayPal when you pay the order.
- Any special request cannot be accepted after 24 hours of payment, because most of orders will be processed instantly and same day dispatched.
- We maintain high standards of excellence and strive for 100% customer satisfaction! Feedback is very important to us. We request that you contact us immediately BEFORE you give us neutral or negative feedback, so that we can satisfactorily address your concerns.
- All package need to wait 30 days(US only need 7-10 days),Please take care it.Less than 30 days,we can't take a refund.
- If the item is defect when you receive it or you are not satisfied with it, please return it within 14 days for a replacement or money back. But the items must be back in factory condition. Please contact us and double check the return address before you return it.
- If is item is defective in 12 months, you can return it to us. We will send you a new replacement after receiving the defective item.
