Product overview:

The UK solar power specialist Photonic Universe Ltd is proud to offer this brand new, high efficiency 540W NU-JD monocrystalline solar panel from leading manufacturer Sharp with 1.75m of special solar cable and MC4 connectors, for charging a 12V battery in a motorhome, camper, caravan, boat or for any other applications.
   Our promise:
  • No-quibble 30 days return period
  • UK repair or replacement warranty
  • Free lifetime technical product support
  • Deep industry expertise and knowledge
    •

330W Sharp NU-JC solar module from Photonic Universe- front


Photonic Universe are proud to present this high quality 540W solar panel from leading solar manufacturer Sharp, which has over 60 years of experience with solar technology and over 50 million solar panels installed all over the world.

This MCS certified panel is perfect for a wide variety of applications, from grid-tie household systems to off-grid installations where mains power is limited or unavailable such as boats, caravans, campervans, cabins or glamping huts. These high-power panels are ideal for large systems where the time and expense of fitting a high Wattage array needs to be minimised.

High efficiency solar cells use PERC technology with 10 busbars to extract more power from a smaller surface area, increasing the output of the panel without increasing the size. The half-cut cell construction decreases internal losses, reduces risk of hotspots and improves performance in shaded conditions.

The robust design of the panel is IP68 (waterproof) rated, and tested for resistance against PID, salt mist, ammonia, heavy snow, dust and sand. This thorough testing ensures a long service life even in harsh marine or wilderness conditions. A pair of male / female MC4 connectors are crimped on the end of the cable for easy waterproof connection to other solar panels, extension leads or your existing system.

With a 15-year workmanship guarantee and 25-year output guarantee, you can be confident in the quality, durability and longevity of this premium solar panel.

Solar Panel Specifications:

  • Peak power: 540W
  • Maximum power voltage: 41.64V
  • Maximum power current: 12.97A
  • Open circuit voltage: 50.34V
  • Short circuit current: 13.66A
  • Power tolerance: 0/+5%
  • Dimensions: 2279 x 1134 x 35 mm
  • Weight: 27.8 kg
  • Mounting holes for ease of installation
  • 2 x 1.75m of high-quality single core solar cable
  • Male and female MC4 waterproof connectors

In order to mount this solar panel on a flat surface (such as a motorhome / caravan / campervan / boat or a metal roof) and avoid drilling, we recommend purchasing the following mounting products: corner mounting brackets, cable gland or a complete mounting set with corner brackets, side brackets and a cable gland.

Please note: if the application of this solar panel is to charge batteries, it is essential that this solar panel is used with a suitable solar charge controller. We recommend the following types of solar charge controllers:

  • For 12V batteries, a high efficiency MPPT solar charge controller rated at 40A or higher
  • For 24V batteries, a high efficiency MPPT / or standard PWM solar charge controller rated at 20A or higher

You can visit the Solar Charge Controllers category of our online shop to view the full range of solar charge controllers available.

If you have any questions about this product or you need our free advice please contact us via eBay messaging (tick the box "This is not about an item" if you don't know this item number).

Payment:

  • We accept Pay Pal, cheques, credit and debit cards, and bank transfer payments. If you choose a cheque payment, please note it might take up to 2-3 weeks to get processed and cleared. Other payment methods are normally much faster, and they should be used for urgent orders. Buy it now listings will require an immediate payment via eBay.

Delivery:

  • Please note that import duties, taxes, and charges are not included in the item price or shipping cost. If the courier requires payment of these local charges to complete the delivery, they will be your responsibility as a buyer.
  • Upon receipt of the item, please examine it carefully. In the unlikely event of any damage in transit, please report it to us immediately by email or phone, but in any case no later than 7 days after receipt of the item. To enable us to deal with the courier efficiently, we may ask for some additional details, e.g. photographs of the damage and packaging.

Returns:

  • If you change your mind within the first 30 days of receipt of the item, we will be happy to accept it back and refund your payment. You will need to notify us via email / phone within 30 days of receipt that you intend to return the item, request the return address and send the item back within a further 14 days at your cost. To be eligible for a full refund, the item must be new, unused, undamaged and correctly packaged. Please ensure that we receive the item in its brand new, original condition, i.e. take reasonable care to wrap and protect it on the way back to us.

Warranty:

  • This product is covered by a 15 year workmanship warranty. In addition, solar cells are guaranteed to produce at least 97.5% of nominal power in the first year after purchase and less than 0.7% degradation of nominal power each year after until 25 years after purchase, for a minimim of 80.7%.

About us

Photonic Universe Ltd is a company based in London, United Kingdom. We design and supply solar and wind renewable energy products and complete off-grid power systems for various applications, to both trade and retail customers. Tens of thousands of clients all over the world rely on our products to generate clean energy for their households, vehicles, boats and remote places with no access to mains electricity.

We strongly believe that solar and wind energy can provide significant benefits and we are doing our best to allow you to buy these quality solar products at fair prices. We've had a lot of positive feedback from our customers who have been impressed by the high quality of our products and excellent service.

We are VAT registered in the UK and can provide VAT receipts upon request. Photonic Universe is a registered trademark in the UK.
