Specifications

Input Features

165M HDMI receiver, max input 2048x1080 60fps 4:4:4

Input RGB/YUV 4:4:4 8/10/12-bit, YUY 4:2:2 12-bit

Up to 8-channel 24-bit HDMI-embedded audio at 192kHz

HDMI interfaces: HDMI 1.4a

Process and Capture Features:

Video processing pipeline up to 160M pixels/s

Capture videos up to 2048x2160, frame rates up to 120fps. Outputs include (actual capture frame rate can be limited by the USB bandwidth and internal working frequency.):

1920x1080p 23.98/24/25/29.97/30/50/59.94/60/75

1280x720p 23.98/24/25/29.97/30/50/59.94/60/100/119.88/120

720x576p25

720x480p30

Support for YUY2/UYVY/RGB24/RGB32

Support video cropping, up/down scaling, de-interlacing, aspect ratio conversion, color format conversion, frame rate conversion, flip and mirror

Up to 2-channel IEC60958 audio streams

Included Software

USB Capture Utility enables users to easily check and set the capture-related parameters, upgrade firmware of the capture device and export info needed for troubleshooting

SDK & APIs

The MWCapture SDK provides functions including signal status extraction, capture configuration and real-time audio & video capture, etc.

Windows DirectShow/Wave API/DirectSound/WASAPI

Linux V4L2/ALSA

macOS AVCaptureSession/AudioUnit

Output Interface:USB 3.0

compatible with USB 2.0

compatible with USB 3.1 Gen 1

Compatible Software

For Zoom Rooms

For Microsoft Teams

For Skype for Business

For Google Hangouts

For GoToMeeting

For Gstreamer

For VLC

For OBS Studio

For XSplit

For QuickTime Player

For Any other DirectShow/V4L2/AVCaptureSession based encoding or streaming software

Recommended OS

Windows 7/8/8.1/10/11/Server 2008/Server 2008 R2/Server 2012/Server 2016 (x86 & x64) and above

Linux x86, x64 & ARM architecture, with 2.6.35 and above

Mac OS X 10.9/

Power Consumption

5V max current: ~0.5 A

Max power consumption: ~2.5 W

Size: 92.2mm (L) x 40.2mm (W) x 12.3mm (H)

Accessories

1 × USB 3.0 cable
