Thunder Tools NOYAFA NF-820 Anti-Interference Underground Cable Locator

NF-820 is a new breakthrough, which are anti-jamming cable detectors for underground, inside-wall or other invisible cable & pipe. The detection range can be up to 2 meters. Besides, NF- 820 is even capable of tracing cable in high voltage environment (0~400V). The current or other live devices can't make influence on it for its anti-jamming function.

It is a practical tool for the engineers, mainly applied in home decoration, cabling installation and telecommunication etc.

Features:

Versatile Wire Tracing: Our underground wire locator is perfect for tracing various metal wires including single metal line, 2-core or multi-core cable, telephone cable, network cable, and multi-strand wire.

Deep Detection Distance: With a detection distance of up to 2 meters deep (6.5ft), our wire locator can help you locate wires quickly and easily.

Long Locating Length: You can locate wires up to 1000 miles (3280ft) with our underground wire locator, making it ideal for large-scale projects.

High and Low Voltage Design: Our wire locator is designed to handle 220V AC to avoid burning and damage of the device. It can also trace cable for DC/AC power below 400V.

User-Friendly Features: Our wire break locator comes with a large-capacity 3.7V lithium battery and can be charged with a USB cable. Additionally, the receiver signal has an indicator light intensity reminder for precise positioning of the cables.

Specifications:

Model: NF-820

Material: ABS

Name: Anti-jamming underground cable detector

Power Supply: Emitter: 3.7V lithium battery 1800mAh

                        Receiver: 3.7V lithium battery 1100mAh

Low Battery Indicate: Emitter:  equal or less than 150mA  plus or minus 10%

                                   Receiver:  equal or less than 80mA  plus or minus 10%

Working Current: Emitter:  equal or less than 3.5V LED light flashlight

                             Receiver: Same as Emitter

Charging Current: 800mA

Signal Transmission Format: Multi-frequency pulse

Signal Output Level: 21Vp-p

Signal Transmission Distance: <10km

Signal Sensitivity Distance: 0~2m

Emitter Size: 152 * 55 * 34mm / 5.98 * 2.16 * 1.34in

Receiver Size: 252 * 45 * 28mm / 9.92 * 1.77 * 1.10in

One Set Size: 262 * 135 * 60mm / 10.31 * 5.31 * 2.36in

Emitter Weight: 143g / 5.04oz

Receiver Weight: 200g / 7.05oz

One Set Weight: 343g / 12.09oz

Package Weight: 500g / 17.63oz

Package Size: 26.5 * 13.5 * 6cm / 10.43 * 5.31 * 2.36in

Package List:

1 * Emitter

1 * Receiver

2 * 3.7V Lithium Battery

1 * 5V 1A Charging Adapter

1 * USB Charging Cable

1 * Earphone

1 * Cloth Bag

1 * User Manual (English)
