Highlights:

1: Low voltage pressure difference. Large current heating less.

2: D25BS60 Schottky Rectifier Bridge, 4pcs P-MOS Transistors parallel Output.

3: Use OP Voltage Follow Circuit

4: The voltage is continuously adjustable between DC 5V---24V

5: Ultra-low noise, low Ripple.

6: 4 PCS IRF9Z34 adopts precise matching.

PCB SIZE: 137*50mm

Output voltage: DC 5V---24V(The default output voltage is DC 12V, (you can also adjust the output voltage yourself)

Output current: Max 12A

(When output high current, need Push soldering on the PCB back Copper skin, and also need to enhance heat dissipation)

Several common output voltages transformer voltage recommend as following:

◆ DC 5V ---- Recommend transformer voltage use AC 9V

◆ DC 9V ---- Recommend transformer voltage use AC 12V

◆ DC 12V --- Recommend transformer voltage use AC 15V

◆ DC 15V --- Recommend transformer voltage use AC 18V

◆ DC 18V ---- Recommend transformer voltage use AC 18V

◆ DC 24V ---- Recommend transformer voltage use AC 24V

NOTE 2: We have DIY kit or Finished board(Optional)

◆ DIY kit ---- All parts need you to solder and test it.

◆ Finished board ---- All parts have been welded and tested OK.
