Era Bi Fold Door Lock Gearbox Replacement 35mm 92mm Fits Warmcore & Liniar Doors
Replacement door and window hardware from a trusted UK specialist.
Fast DispatchTracked Delivery30 Day Returns
Product Images
Product images will appear here when available.
Additional product image not available.
Additional product image not available.
Additional product image not available.
Additional product image not available.
UPVCSTORE Listing
Era Bi Fold Door Lock Gearbox Replacement 35mm 92mm Fits Warmcore & Liniar Doors
Family-Run UK BusinessMarketplace Safe CheckoutSpecialist Product Support
Product Summary
Brand
ERA
EAN
7426983217656
SKU
C 199
Weight
0.3
Why Buy From UPVCSTORE?
We specialise in replacement hardware for uPVC windows and doors, with experienced advice, dependable dispatch, and support before and after your purchase.
ERA Bi-Fold Door Lock Gearbox Replacement 35mm 92mm Fits Warmcore & Liniar Doors
This replacement hook gearbox is designed specifically for Warmcore and Liniar bi-folding doors. It features a 35mm backset (measured from the handle spindle center to the front of the lock faceplate) and a 92mm PZ. Since the gearbox is the most common point of failure in a bi-folding door lock, replacing it is a cost-effective solution that avoids the need to purchase an entirely new locking mechanism.
Features:
Compatible with Warmcore and Liniar bi-folding doors
Non-handed design, suitable for both left- and right-handed doors
Single spindle for lever/lever door handle operation
What’s Included?
1 x ERA Bi-Fold Door Lock Hook Gearbox (35mm backset, 92mm PZ)
Dimensions:
Lock case height: 50mm
Lock case width: 220.5mm
Lock case depth: 14.5mm
Centre of latch to deadbolt centre: 85.5mm
Deadbolt width: 25mm
Deadbolt thickness: 10mm
Distance between first and second faceplate screw holes: 42.5mm
Distance between second and third faceplate screw holes: 85.5mm
PZ measurement: 92mm
Backset measurement: 35mm
Features and Details
ERA Bi-Fold Door Lock Gearbox Replacement 35mm 92mm Fits Warmcore & Liniar Doors
ERA Bi-Fold Door Lock Hook Gearbox for Warmcore and Liniar Doors – 92mm PZ
This replacement hook gearbox is designed specifically for Warmcore and Liniar bi-folding doors. It features a 35mm backset (measured from the handle spindle center to the front of the lock faceplate) and a 92mm PZ. Since the gearbox is the most common point of failure in a bi-folding door lock, replacing it is a cost-effective solution that avoids the need to purchase an entirely new locking mechanism.
Features:
Compatible with Warmcore and Liniar bi-folding doors
Non-handed design, suitable for both left- and right-handed doors
Single spindle for lever/lever door handle operation
What’s Included?
1 x ERA Bi-Fold Door Lock Hook Gearbox (35mm backset, 92mm PZ)
Dimensions:
Lock case height: 50mm
Lock case width: 220.5mm
Lock case depth: 14.5mm
Centre of latch to deadbolt centre: 85.5mm
Deadbolt width: 25mm
Deadbolt thickness: 10mm
Distance between first and second faceplate screw holes: 42.5mm
Distance between second and third faceplate screw holes: 85.5mm
PZ measurement: 92mm
Backset measurement: 35mm
