75V 12A High Current Ideal Diode Anti-reverse Solar Charging Protect Module

Popular

    Product Introduction

    Features:
    1: Widely used
    2: High efficiency
    3: Solar panels prevent backflow
    4: Small size
    5: Simple to use
    The main parameters
    Input voltage: 9-75V
    Turn-on internal resistance: 4 milliohms
    Working temperature: -20 to 100 degrees
    Peak current: 20A
    Standby current: 0.7MA (at 24V)
    Continuous working current: below 12a
    Size: 23*14*2.6mm

    Precautions:
    There is no anti-reverse connection function, do not reverse the input positive and negative poles when the ambient temperature is high and the ventilation is not good
    Please reduce the output current

    Use:
    *Instead of ordinary diodes, heat is small
    Pressure reduction and high efficiency
    Anti-overflow of solar panels
    *Battery charging to prevent backflow
    *DC power charging to prevent backflow
    *Isolation of power supply and inductive load

    Package Included:
    1* Diode module
