The Topcon RL-H5A Laser provides dependable accuracy and long-range performance for construction and site leveling tasks. With ±1/16 in accuracy at 100 ft and a working diameter of 2,600 ft (800 m) using the LS-80L receiver, the RL-H5A is a reliable reference for concrete, foundations, excavation, and general layout. Automatic electronic self-leveling and manual slope capability make setup fast and straightforward, while the rugged IP66-rated housing ensures durability in tough jobsite conditions. Powered by four D-cell alkaline batteries, it offers up to 100 hours of operation for uninterrupted productivity.

This package includes the RL-H5A rotary laser, LS-80L receiver with holder, an aluminum tripod, and a 13 ft fiberglass grade rod with feet/10ths graduations. The fiberglass rod provides extra durability for demanding field environments, while its tenth graduations make it ideal for precise grade checks on construction sites.

Specifications

• Model: Topcon RL-H5A Self-Leveling Rotary Laser
• Laser Class: Class IIIa (FDA), Class 3R (IEC)
• Laser Source: 635 nm visible red diode
• Operating Range: 2,600 ft (800 m) diameter
• Accuracy: ±1/16 in @ 100 ft (±10 arc seconds)
• Self-Leveling Range: ±5°
• Manual Slope Capability: Yes
• Rotation Speed: 600 rpm
• Status Alerts: HI alert, low battery
• Battery Options: 4 × D-cell alkaline (100 hrs) or rechargeable NiMH pack (60 hrs)
• Operating Temperature: -4°F to 122°F (-20°C to 50°C)
• Protection: IP66
• Warranty: 5 years

In the Box

• RL-H5A laser with receiver, Sensor holder and Tough carrying case
• Aluminum Tripod
• 13 ft Fiberglass Grade Rod (Tenths)
