Model number | K26 |
Screen | 2.0inch IPS screen , 320x240P MIPI interface |
CPU | SA230D Arm Cortex-A7 CPU+RISC-V CPU |
DDR | 1GB DDR3L |
4G Module | Quectel EC800K |
Storage | RAM | 128MB |
ROM | 128MB |
GPS | Built in GPS+Beidou dual module GPS antenna |
OS | Linux |
Network Band | 4G FDD-LTE: B1/B3/B5/B8, TDD-LTE: B38/B39/B40/B41 |
Dual camera resolution | Front camera is 4K/3840*2160@25fps ,wide angle 140 °;
Back camera is 1K/1920x1080@25fps , wide angle view is 130° |
Remote monitor | Support mobile APP remote live-view and monitor, remote playback/capture image,
remote TF card formatting, remote restart, remote download video files from sd card. |
BSD | Support |
ADAS | Support |
GPS track history playback | Support |
Video file playback and download | | Support check video file by SD card or download the video file into mobile phone to playback |
G-Sensor | 3-axis G-Sensor, support Loop Recording |
Parking Monitor | 3-axis G-Sensor, support Parking Monitor |
Time lapse | Support 12Hrs or 24Hrs time lapse recording |
Video compression format | H.264 |
Video format | TS |
Software upgrade | Upgrade by TF card, OTA online upgrade. |
WiFi | 802.11 b/g/n 2.4Ghz; support wifi hotspot |
External memory card | Support micro sd card, maximum 512GB(not included) |
MIC | Build in MIC-Phone Noise Reduction |
Speaker | Build in speaker ( 1.5W/8R speaker) |
Key button | 2 buttons |
RESET | Support |
Powered by | External power | DC12V, Type-C plug-in Input 12V, support 12~24V |
ACC | Support ACC checking |
Temperature
and humidity range | Temperature | Usage: -20~+70°C |
Storage: -30~+80°C |
Mobile APP name is "CloudSpirit" for Android/ iOS |
App for Android/iOS | CloudSpirit |
Real-time preview | Yes |
Remote capture image | Yes |
Remote capture video | Yes |
Monitor and Alarm | Yes, Support Message / photo alarm if collision happened when car parking |
GPS logger track history playback | Yes, could support 6 months GPS history search and playback |
Two way voice talk | Yes, just need press the app microphone button one time, and then could talk to the driver |
Live-view image Zoom in & Zoom out | Yes, support live-view window image zoom in & zoom out |
Video download | Yes, support remotely download video files from sd card |
Administrator | The first user who bind the dashcam , will become the administrator,
the admin account could share the QR code to other user to monitor this dashcam, also could delete the user account as need. |
