ANCEL PB100 Power Circuit Probe Electrical Integrated Voltage Scanner Tool 24V
ANCEL PB100 Product Description
ANCEL PB100 circuit tester is a fast and efficient electrical Scanning probe, works for all 12V and 24V electrical system, like cars, boats, trailers, fuel pumps, relays and many other Vehicles.
The ANCEL PB100 power scan kit is the most revolutionary circuit tester to date, featuring AVOmeter, test light , built -in flashlight , short circuit indicator , relay/component tester , continuity tester and bad groud indicator , the power scan is truly the ultimate in power and affordablity , allowing users to check circuitry in one single step . an absolute must for every technician looking for a fast and accurate solution to electrical systems diagnostics.
Product Specifications
Display：TFT color display (160x128 dpi )
Supply Voltage：DC: 8V ~ 35V
Operating Temperature：0 to 60℃ ( 32 to 140℉)
Storage Temperature： -40 to 70℃ (-40 to 185℉ )
Dimensions (L*W*H)：178*47*28mm (7*1.85*1.10in )
DC/ AC Voltage Test： -110V ~ +110V (True RMS Measure)
ANCEL PB100 Product Function:
There are four modes to diagnose the electrical systems, which can be accessed by depressing the Mode Button and cycling through each one.
✔️DC voltage
While the tool in this mode, contact the probe tip to a circuit, then the LCD display will read the DC voltage with a resolution of 0.1 volt.
✔️AC voltage
While the tool in this mode, contact the probe tip to a circuit, then the LCD display will read the Max. voltage, the Min. Voltage and frequency.
✔️Resistance
While the tool in this mode, contact the probe tip to a circuit, then the LCD display will read the resistance between the tip and auxiliary ground lead.
✔️Diode
In this mode, the probe tip contact the positive terminal of the diode, connect the auxiliary ground lead to the negative terminal of the diode, the screen will display the forward voltage drop, indicates the forward bias. If exchange the probe tip and auxiliary ground lead, the screen will not display the voltage, indicates the reversebias.
Top Reasons to Chose Ancel PB100 Circuit Tester
1. Extremely easy to use and highly reliable
2. Built-in Flashlight enables you to work in the dark
3. Easy to read AVOmeter allows you to read voltage, current and resistance at the fingertip
4. With 6 Meter long electronic cable, convenient to test around the car
5. Test mode contain AV Voltage, DC Voltage, Current Resistance, LED, including most car circuit test system
6. Including Cigarette Lighter adaptor, battery test clips, easy to get supply in the car
2. Built-in Flashlight enables you to work in the dark
3. Easy to read AVOmeter allows you to read voltage, current and resistance at the fingertip
4. With 6 Meter long electronic cable, convenient to test around the car
5. Test mode contain AV Voltage, DC Voltage, Current Resistance, LED, including most car circuit test system
6. Including Cigarette Lighter adaptor, battery test clips, easy to get supply in the car
Key Features & Functions:
1: Perform power injection, measuring, ground testing, polarity checking, continuity testing and component activation.
2: Find short to ground and short to voltage.
3: Automatically detect the positive, negative and open circuit.
4: Three additional modes: MIN / MAX / Audible Monitoring.
5: AC-RMS, AC Peak to Peak, Frequency and Pulse Width for signal testing.
6: High Voltage Capability: display up to 60 Volts, Resolution of 0.1 Volt.
7: 8 Amp Circuit Breaker Protection, automatically Reset, No Button to Push.
8: Comes with 20 foot Power lead and extra 20FT extension cable.
9: 2 power source: Vehicle battery and cigarette lighter.
10: Larger brighter color LCD display and easy menu navigation.
11: Ergonomic housing design with water resistant rugged blow molded case, easy to handle and store.
12. Read the AVO meter, voltage, current, and resistance easily.
13. Press the power switch lightly and get the instant heat ground lead to energize the electrical components, such as the cooling fan, relay etc.
14. Activate the components by using the hot wire and ground lead simultaneously.
15. Determine the positive, negative and open circuit quickly.
16. Test the bad ground contacts quickly, follow and locate short circuits without wasting the fuse.
17. Test the continuity of the power switch, relay and diode quickly.
18. Protect the tool from overload through the inner circuit breaker.
19. Bulit-in flashlight enables you to work in the dark.
20. Circuit breaker protected.
2: Find short to ground and short to voltage.
3: Automatically detect the positive, negative and open circuit.
4: Three additional modes: MIN / MAX / Audible Monitoring.
5: AC-RMS, AC Peak to Peak, Frequency and Pulse Width for signal testing.
6: High Voltage Capability: display up to 60 Volts, Resolution of 0.1 Volt.
7: 8 Amp Circuit Breaker Protection, automatically Reset, No Button to Push.
8: Comes with 20 foot Power lead and extra 20FT extension cable.
9: 2 power source: Vehicle battery and cigarette lighter.
10: Larger brighter color LCD display and easy menu navigation.
11: Ergonomic housing design with water resistant rugged blow molded case, easy to handle and store.
12. Read the AVO meter, voltage, current, and resistance easily.
13. Press the power switch lightly and get the instant heat ground lead to energize the electrical components, such as the cooling fan, relay etc.
14. Activate the components by using the hot wire and ground lead simultaneously.
15. Determine the positive, negative and open circuit quickly.
16. Test the bad ground contacts quickly, follow and locate short circuits without wasting the fuse.
17. Test the continuity of the power switch, relay and diode quickly.
18. Protect the tool from overload through the inner circuit breaker.
19. Bulit-in flashlight enables you to work in the dark.
20. Circuit breaker protected.
21. FREE GIFT - 20ft(extendable) cable, it provides excellent accesssiblity to test along the vehicle.
Operate the tool without looking at the menu once users are familiar with the tone. Test along the vehicle by the long cable.
Operate the tool without looking at the menu once users are familiar with the tone. Test along the vehicle by the long cable.
Features:
1. Powerful and Mulit-function, One Tester Multipurpose
PB100 Professional Power Circuit Probe, support 10 functions: Voltage & Polarity Testing, Continuity Testing, Signal Circuit Testing , Activating Components in hand as well as in the vehicle. And Testing Trailer Lights and Connections, Activating Components W/Ground, Red/Green Polarity LED, Following & Locating Short Circuits, Checking for Bad Ground Contacts
PB100 Professional Power Circuit Probe, support 10 functions: Voltage & Polarity Testing, Continuity Testing, Signal Circuit Testing , Activating Components in hand as well as in the vehicle. And Testing Trailer Lights and Connections, Activating Components W/Ground, Red/Green Polarity LED, Following & Locating Short Circuits, Checking for Bad Ground Contacts
2. Two Different Power Source, Worry-Free
Powered via the vehicle by connected to battery cigarette or battery electrode.
3. Built-in Red/Green Polarity LED
Easy to Determine the Positive, Negative and Open Circuit
4.LCD Screen Display, Easy to Read Indicated Test Results
A Large color LCD screen, can display all the test result, save your time on diagnose car electrical problems.
5.Head Lights & Audio Tone, Make It Possible to Work in the Dark
Built-in front LED flashlight , allow to work in the dark environment. Audio tone indicator allows for no-look menu scrolling once users are familiar with menu tone assignment.
6.Circuit Breaker Protection Technology
Ability to Power Up Components. Automatically shut-off if current exceeds 5 Amperes, it design to protect an electrical circuit from damage caused by over current, typically resulting from an overload or short circuit.
7.Superior Quality
Powered via the vehicle by connected to battery cigarette or battery electrode.
3. Built-in Red/Green Polarity LED
Easy to Determine the Positive, Negative and Open Circuit
4.LCD Screen Display, Easy to Read Indicated Test Results
A Large color LCD screen, can display all the test result, save your time on diagnose car electrical problems.
5.Head Lights & Audio Tone, Make It Possible to Work in the Dark
Built-in front LED flashlight , allow to work in the dark environment. Audio tone indicator allows for no-look menu scrolling once users are familiar with menu tone assignment.
6.Circuit Breaker Protection Technology
Ability to Power Up Components. Automatically shut-off if current exceeds 5 Amperes, it design to protect an electrical circuit from damage caused by over current, typically resulting from an overload or short circuit.
7.Superior Quality
Ergonomic rugged & water-resistant housing design, built-in LCD screen(indicate testing result) and head lights(wok in the dark), packaged with a case，easy to installing and using, provide you a superior user experience.
8. 4 Diagnostic Modes
8. 4 Diagnostic Modes
Depressing the Mode Button and cycling through each modes like DC Voltage, AC Voltage, Resistance and Diode modes to diagnose the 12v-24v electrical systems.
9.Powerful Function
9.Powerful Function
power injection, measuring, ground testing, polarity checking, continuity testing and component activation，KM10 circuit tester work for cars, boats, trailers, ATV, motorhomes and many other vehicles.
When the current exceeds 8A
When the current is overloaded,the tester will automatically break protection yo reduce unnecessary losses.
When the current is overloaded,the tester will automatically break protection yo reduce unnecessary losses.
99% Vehicles Coverage:
This convenient & efficient circuit probe tester is made to DIY auto enthusiasts, electronics engineers, and technicians with many electrical problems. The electric circuit tester can be widely use for all 12V-24V vehicle elecrtical system diagnostics, such as cars, trucks, motorcycles, pickups, boats and farm machinery etc. It popularly used in service shops, schools, homes, and industries.
PB-100 with Case and Accessories :
1. The Ultimate in Circuit Testing
2. PB-100 Circuit tester with the ability to supply Power or Ground with an indicator tone and bright-white LED headlamps.
3. Features Digital Voltmeter, Min/Max, Audible Circuit Monitoring, 4mm Standard Banana Jack and Auxiliary Ground for component testing.
4. Includes Case and extension Lead cable for 12 Volt Power Port Adapter.
5.External Power: 12.0 or 24.0 V power provided via vehicle battery.
6.Display: TFT color display (160 x 128 dpi).
7.Operating Temperature: 0 to 60°C (32 to 140°F)
2. PB-100 Circuit tester with the ability to supply Power or Ground with an indicator tone and bright-white LED headlamps.
3. Features Digital Voltmeter, Min/Max, Audible Circuit Monitoring, 4mm Standard Banana Jack and Auxiliary Ground for component testing.
4. Includes Case and extension Lead cable for 12 Volt Power Port Adapter.
5.External Power: 12.0 or 24.0 V power provided via vehicle battery.
6.Display: TFT color display (160 x 128 dpi).
7.Operating Temperature: 0 to 60°C (32 to 140°F)
Package Lists
1 x PB100 Circuit Probe
1 x Extension Cable (20ft)
1 x Battery Hookup Clips
1 x Cigarette Lighter Adapter
1 x Protective Case
1 x Probe tip
1 x User's Manual
