GEYA 8 Pins 4PDT Electromagnetic Relay

Applications

Dual function time relay can be used for industrial equipment,lighting control,heating element control,motor and fan control,with two delay modes,and the delay range covers 0.1 seconds to 10 days.

Feature

Operate the coil
Rated voltage V	Dc12v	DC24V	DC110V	Dc220V
Rated current (10%)mA	75	37.5	8	1
Coil resistance (10%) Ω	160	640	13444	53778
Rated power consumption W	0.9W
Suction voltage (max) V	Below 75%
Release voltage (min) V	More than 10%
Allowable voltage (max) V	Rated voltage x110%

Rated voltage V	Dc12v	DC24V	DC110V	Dc220V
Rated current (10%)mA	100	50	10.9	5.4
Coil resistance (10%) Ω	42	168	3529	14116
Rated power consumption W	1.2VA
Suction voltage (max) V	Below 80%
Release voltage (min) V	More than 30%
Allowable voltage (max) V	Rated voltage x110%

Product technical parameters
Contact resistance	≤100m2
Electrical life	1x10⁵ times
Mechanical life	1x10⁴ times
Coil voltage	DC:6-220V AC:6-380V
Aspiration time	≤15ms
Release time	≤10ms
between the contacts of the same poles	1000VAC/1min (leakage current lmA)
Between heteropolar contacts	1000VAC/1min (leakage current 1 mA)
Between the contacts and the coil	1500VAC/1min (leakage current 1 mA)
Insulation resistance	≥100MΩ(500VDC)
Ambient temperature	-25°C~ 55°C
Ambient humidity	35% ~80%RH
atmospheric pressure	86 ~106KPa
Impact resistant	10G (Sine Wave Half-Pulse: 11ms)
Vibration resistant	10-55Hz dual amplitude: 1.5mm
size	27.3 x 21 X 35mm
weight	About 40g
