Note:
1. The radiator cap that has not passed the test can’t release the pressure when it reaches the pressure value.
2. The damaged thermostat is unable to carry out a large cycle, resulting in a continuous increase in the radiator pressure.
3. The radiator fan does not turn, resulting in high temperature in the water tank.
4. Drain the air from the cooling system. Refer to the user manual or repair manual.
5. Please refer to owner's manual to add coolant.
6. Do not open the hood until the steam has subsided. The engine compartment may be very hot, causing serious injuries such as burns.
7. Please stop the vehicle immediately, when “ENGINE OVERHEAT/High Temperature” shows on the dashboard or steam comes out from under the hood.
8. Keep hands and clothing (especially a tie, a scarf) away from the fans and belts. Failure to do so may cause the hands or clothing to be caught, resulting in serious injuries.
9. Do not loosen the radiator cap while the engine and radiator are hot. Serious injuries, such as burns, may result from hot coolant and steam released under pressure.

Features:
Enhancements added to solve original design failures and to improve the life of high mileage vehicles
Drop in fit, form and function for hassle-free installation
All necessary hardware or fittings are included in each unit
100% Leak Tested
Premium grade tubes, fins, headers, tanks, and other components
Components are fitted and torqued in place to factory specifications

Part Number：

CU13199,CU13197,GM3010540,GM3010541,Q13197

Fitment:
2011 - 2013 For chevrolet Cruze 1.4L &1.8L

Package:
1pc of brand new radiator

Warranty:
30 days free return and exchange
5 years warranty

How to clean radiator:
1. Start the vehicle, to rise to normal temperature. Slowly open the tank cover, the fluid shake from the tank after filling the mouth, the cleaner can be mixed with any brand of coolant. Idle running not less than 15 minutes, not cleaning vehicles not less than 30 minutes for two years. And then discharge coolant, flush water tank, until out of clear water, suitable for any water cycle system.
2. After cleaning, after waiting for pipeline rehabilitation add fluid to water tank, and inject new coolant and water purification.
How to replace the radiator:
1. Disconnect the battery.
2. Drain the radiator fluid into a suitable container.
3. Remove the old radiator:
-Take off any plastic covers around the radiator.
-Disconnect the electrical connector to the fan, and unbolt and remove the fan assembly.
-Disconnect the radiator hoses from the radiator.
-Disconnect the transmission cooling lines from the bottom of the radiator.
-Remove any clamps, brackets, or screws holding the radiator inside its frame.
-Lift the radiator up and out of the car.
4. Install the new radiator:
-Slide the new radiator into place.
-Connect any clamps or brackets that hold the radiator in place.
-Connect the transmission cooling lines carefully.
-Connect the engine cooling hoses to the radiator.
-Replace the fan and fan shroud.
-Reconnect the fan electrical connection.
-Replace the plastic covers.
5. Fill the radiator with fluid.
6. Check your work to make sure that there are no leaks.
(Tools need to be prepared: Screwdrivers, Wrenches, Drain pan)
Note: Do please keep children and pets away when replacing the radiator)

Item Specifics
Brand	KAC
Type	Radiator
Material	Aluminum, Plastic
Features	Crossflow Radiator
Manufacturer Part Number	65ERSH4561
OE/OEM Part Number	8013197,A13199,CU13197
Manufacturer Warranty	5 Years
Outlet Diameter	1-5/16 IN
Interchange Part Number	13199,13267669
Superseded Part Number	CU13199
Inlet Diameter	1-1/2 IN
Fitment Type	Direct Replacement
Core Height	26-3/4 In.
Core Thickness	1 In.
Transmission Type	Manual Transmission
Core Width	15-5/8 In.
Engine Oil Cooler Included	No
Compatible Makes	For Chevrolet
Model	For Cruze, Cruze Limited
Year	2011-2016
Engine Type	L4 1.4L, L4 1.8L
Radiator Row Type	1 Row
Cap Included	No
Trans Oil Cooler Included	Yes
