①Product Specifications
Size: 16x16x16(cm)
Weight: 1.6kg
Material: Aluminum
Color: Silver
Placement on Vehicle: Front
Hose Port Type: Seat
Housing Material: Aluminum
Power Steering Outlet Thread Size: M16*1.5
Power Steering Outlet ID Size:
Power Steering Pump Inlet Attachement Type: Hose Barb
Power Steering Pump Outlet Attachment Type: Threaded
Pulley Attachement Type: Press on
Pulley Included: Yes
Reservoir Included: No
②OEM/Interchange Part Numbers
4431002101, 88970127，21-5345
③Fitment
Pontiac Vibe 2003 - 2006
Pontiac Vibe 2007 - 2008
Toyota Corolla 2003 - 2004
Toyota Corolla 2005 - 2006
Toyota Corolla 2007 - 2008
Toyota Matrix 2003 - 2006
Toyota Matrix 2007 - 2008
④Features
Built to strict quality control standards 100% factory tested
IATF16949
100% Compatible with OEM Parts, meets Original Equipment Manufacturer (OEM) Standards
This steering pump is made of high-quality material and maintains an excellent strength to give the parts long-term performance
the reservoir into the steering gear and keeps the wheels running in the right conditions
This steering system pump is a direct replacement. If your original power steering pump is failing or leaking, this replacement steering pump could be your solution.
If you have symptoms like whining noise while turning the wheel, steering wheel slow to respond, stiff steering wheel, or squealing & groaning noises when the vehicle starts, and you might need to replace your old Power Steering Pump with this one.
⑤Package Include
1PC Power Steering Pump
⑥Attention
Ⅰ 1. When disassembling the steering pump of the original car,drain the
original old hydraulic oil at the same time.
2.Clean the oil can and the oil pipe, check whether the oilcan is
damaged,check whether the filter of the oil can isblocked,check whether
the oil inlet hose is hardened andaging, prohibit the oil with impurities, and
prohibit the oil fromturning black and opaque
Ⅱ 1.When installing the steering pump,you must lock the oilinlet pipe clamp
and check whether it is firmly to prevent airintake.
2.Replace the sealing ring of the high pressure oil pipelinking the steering
pump to prevent oil leakage, resulting inmisjudgment of oil leakage from
the steering pump.
Ⅲ note! Follow the process
1. Instali the steering pump
2. Fill the oil pot with oil,
3. After starting the engine, do not turn the steering wheelLet the steering
pump circulate the oil by itself. Observe theoil in the tank and replenish the
oil in time until the properlevel is reached.After the installation is complete,
turn thesteering wheel at last.
⑦Note
before installation, be sure to clean the oil pot and oil pipe. lfthere are impurities, after the car is running, the impurities inthe oil pot and oil pipe will enter the steering pump, resultingin the pump not working.
Once the pump does not work.
please contact us in time and we will send a video of cleaningthe pump. Then follow the steps in the video to clean thepump, the pump will be Ok.
