Band Pass Filter 433MHz BPF Passive Filter 433MHz ±20MHz Bandpass Filter 13dbm

Popular

    Product Introduction

    Features:
    1: Widely used
    2: Simple to use
    3: Working frequency 433±20MHz
    4: Maximum input signal strength 13dbm (20mw)
    5: Input impedance 50 ohms output impedance 50 ohms

    Description:
    Name: Band Pass Filter
    Working frequency: 433±20MHz
    Insertion loss: 2.8db
    Out-of-band rejection: 40dB @ 50MHz
    Input impedance: 50 ohm
    Output impedance: 50 ohm
    Maximum input signal strength: 13dbm (20mw)
    Input interface: SMA-K (SMA female)
    Output interface: SMA-K (SMA female)

    Packing list:
    1x Band Pass Filter 433MHz BPF Passive Filter 433MHz ±20MHz Bandpass Filter 13dbm
