iCON AIO6 USB Audio MIDI Device and Control Surface

iCON AIO6 USB Audio MIDI Device and Control Surface
A complete solution for your home studio - the iCON AIO6 is both an audio interface and a control surface. It provides 6 inputs/6 outputs, 2 mic preamps, a 4-channel control surface, and a 24bit/192kHz audio interface. MIDI in/out and S/PDIF as well. Dual headphones outputs located on either side of the interface.

Audio Interface
Incorporating a total of 6 inputs and 6 outputs at a resolution of up to 24 bit, 192 kHz over USB. There are 2 dual microphone / instrument preamps with individual gain control and phantom power, 2 analogue line inputs and 4 outputs on balanced TRS jacks, as well as 2 headphone outputs and S/PDIF I/O.

Control Surface
The control surface has four channel strips, each with a volume fader, mute, solo, and rec arm buttons, and an encoder to control pan position or send levels. There is an additional fader and encoder for the master channel. A jog wheel, a six-button transport, and navigation buttons are also provided to quickly operate any recording session. The AIO6 uses Mackie Control and HUI protocols for presets and automatic mapping, but also features dedicated user mode buttons to recall custom user mappings on the fly. The AIO6 comes bundled with Cubase LE and includes factory presets for most popular DAW's including Cubase, Nuendo, Logic Pro, Pro Tools, Ableton Live, and Samplitude. Every control can be custom-mapped to any MIDI application using the included iMap software.

Features:

• 4×4 analog I/O full duplex recording and playback
• Dual MIC/Instrument preamps with individual gain control and phantom power switch
• 2 analogue line inputs on 1/4″ TRS jacks
• 4 analog outputs on 1/4” TRS jacks
• S/PDIF I/O on RCA coaxial connectors
• 1 x 1 – 16 channel MIDI I/O
• 2- faders volume controls on the front panel
• 2 headphone output with channel 1/2 & 3/4 selectable switches and individual volume control
• Flexible channel routing via the software control panel
• 4-channel faders plus one master channel fader
• 5 encoder knobs
• Jog wheel shuttle for fast search and control
• Buttons for each channel including Rec-enable, Solo and Mute
• “Channel/Bank” with “Up/Down” buttons for shifting channel by track or page
• Transport buttons including Play, Stop, Rec, Rewind, Fast forward and Loop
• Zoom keys for L/R & Up/Down
• Marker keys for Prev/Next & Up/Down
• Mixer, Edit, Save and Undo functions
• Ex-Control connector for connecting up to 3 external control pedals (Optional EC-3 splitter cable and SPD-01 pedal are needed)
• Supports DirectSound, WDM and ASIO2.0
• Class-compliant with Windows XP, Vista (32-bit), Windows 7 (32-bit & 64-bit),  Windows 8 (32-bit & 64-bit),Windows 10 and Mac OS X (IntelMac)
• Full duplex, simultaneous record/playback
• Mackie control built-in for Cubase, Nuendo, Samplitude, Logic Pro and Abelton Live.
• Mackie HUI protocol built-in for Pro Tools.
• Robust aluminum and metal casing with Kensington lock port

Specifications:
