4 x V2, 5mm thickness, Angled L Brackets, Polished Clear Transparent Acrylic + 20x M5 Bolts, Clear Right Angle Bracket, Corner
Product Highlights
- 4x Brackets Pack. Acrylic Brackets. Length: 70mm. Width: 30mm. Thickness: 5mm. SKU: 566
- Clear acrylic brackets are totally transparent and 5mm thick. They have a high quality, polished gloss finish. No seams - just a solid single piece design.
- 4x holes are pre-drilled for convenience. Bolt holes are 10mm from edge to centre point of hole. 5mm diameter holes.
- 20x Clear M5 x 16mm Bolts, Nuts & Washers are included in package. Please see technical image for dimensions.
- Acrylic is a strong, tough, and durable material with good impact strength, being 50% lighter than glass.
Please see the technical image illustration for size references. All measurements are in millimetres/millimeters.
Product Details
- SKU: 566
- Product Type: Acrylic Brackets
- Size: 70mm
- Color: Clear
- Main Material: Acrylic / Polycarbonate
- Material 2:
- With Tape?: No
- Quantity: 4 Pack
- Length: 70 mm (L)
- Width: 30 mm (W)
- Depth/Thickness: 30 mm (D)
- Length - Inches: 2.756
- Width - Inches: 1.181
- Depth/Thickness - Inches: 1.181
Dimensions (L x W x D mm)
70 mm (L) x 30 mm (W) x 30 mm (D)
Additional Specifications
Product Description
4x Brackets Pack. Acrylic Brackets. Length: 70mm. Width: 30mm. Thickness: 5mm. SKU: 566
Clear acrylic brackets are totally transparent and 5mm thick. They have a high quality, polished gloss finish. No seams - just a solid single piece design.
4x holes are pre-drilled for convenience. Bolt holes are 10mm from edge to centre point of hole. 5mm diameter holes.
20x Clear M5 x 16mm Bolts, Nuts & Washers are included in package. Please see technical image for dimensions.
Acrylic is a strong, tough, and durable material with good impact strength, being 50% lighter than glass.
Acrylic has a light transmission of up to 92%, making it a popular alternative to glass in applications where optical clarity is required. It has inherent UV resistance. The material is moisture resistant, strong, durable and lightweight, with impact resistance at least 100 times greater than glass. It is used for joining and reinforcing corners where perpendicular parts meet, and also for fixing to a panel or wall at the back of a cupboard, cabinet, etc. Also known as , Acrylic Corner Bracket, Acrylic L Bracket, Acrylic Right Angle Bracket
Clear acrylic brackets are totally transparent and 5mm thick. They have a high quality, polished gloss finish. No seams - just a solid single piece design.
4x holes are pre-drilled for convenience. Bolt holes are 10mm from edge to centre point of hole. 5mm diameter holes.
20x Clear M5 x 16mm Bolts, Nuts & Washers are included in package. Please see technical image for dimensions.
Acrylic is a strong, tough, and durable material with good impact strength, being 50% lighter than glass.
Acrylic has a light transmission of up to 92%, making it a popular alternative to glass in applications where optical clarity is required. It has inherent UV resistance. The material is moisture resistant, strong, durable and lightweight, with impact resistance at least 100 times greater than glass. It is used for joining and reinforcing corners where perpendicular parts meet, and also for fixing to a panel or wall at the back of a cupboard, cabinet, etc. Also known as , Acrylic Corner Bracket, Acrylic L Bracket, Acrylic Right Angle Bracket
