JOYO JP-05 Power Supply 5 - Rechargeable Battery Powered

JOYO JP-05 Power Supply 5 - Guitar Effects Pedal Power Supply with USB Charge Port and Rechargeable Battery
The JOYO JP-05 Power Supply 5 is the next step in innovation for musicians by JOYO. Featuring 8 DC outputs with up to 500mA of available output current, as well as a USB device charging port, switchable 9, 12 and 18V DC power output, as well as a built in fast-charge rechargeable lithium battery pack, the JP-05 is the perfect fully portable multi pedal power supply for any gigging musician!

Each output features independent filters, output overload & short-circuit protection, which protecting your pedals and filters out any unwanted noise.

Portable and Practical
The Power Supply 5 is packed with additions to suit any pedalboard setup! The 7.4v/4400 mAh rechargeable lithium battery is able to be fully charged within 2.5 hours, and is still able to be used directly connected to mains power. 8 brightly lit blue LED lights glow above each output, and are able to switched off manually when in battery mode, to conserve power. A top facing LED battery indicator light is well displayed and always easy to see, removing the risk of losing your power on stage. The JP-05 provides 3x 9V DC outputs with 500mA of current, as well as an additional 4x 100mA connections, and switchable 9V, 12V or 18V 100mA output.

With the JP-05, the internal 7.4 V / 4400 mAh lithium battery can last:
 - About 2 hours when running high-current digital pedals
 - More than 10 hours when powering 8 analog pedals

Why Power Stations are Important
Powering 4 or 5 pedals with a daisy chain is fine if they are relatively low 'current' consumption pedals, but if you're powering more than this off a single 9V AC/DC adapter you can overdraw the power supply and create electrical issues within the pedals. This can often result in unwanted buzz or noise in your audio signal. The JP-05 power brick can be used to daisy chain up to 15 standard 100mA pedals with no risk of noise or current overload.

Item Includes:

 - JOYO JP-05 "Power Supply 5"
 - 8x DC patch cable with right angle plug - 50cm (5.5mm x 2.1mm)
 - 1x polarity converter cable
 - 9V 2000mA power adapter

Features:

• Compact design suitable for many pedal boards
• Standard 9V outputs suit nearly all common effects pedals
• Isolated low noise outputs
• Bright blue LED channel lights with on/off control
• Top facing battery level indicator
• Short circuit and current protection
• 5V USB device charging port
• Stylish orange on black finish
• Fast 2.5 hour charge time
• Fully portable

Specifications:

• Model: JP-05
• Battery Capacity: 4400 mAh
• Isolated Centre Negative DC9V Outputs:
  • 4x 100mA
  • 3x 500mA
• 1x 100mA Switchable 9/12/18V Output
• Dimensions: 146mm x 65mm x 35mm
