Product List
AMD EPYC 7502 * 1Supermicro H12SSL-i * 1
Product Specifications
AMD EPYC 7502：| Category | Specification |
|---|---|
| Model | AMD EPYC 7502 |
| Processor Family | AMD EPYC™ 7002 Series (Rome) |
| Architecture | AMD Zen 2 (Rome) |
| Cores / Threads | 32 Cores / 64 Threads |
| Base Clock | 2.50 GHz |
| Max Boost Clock | Up to 3.35 GHz |
| L3 Cache | 128 MB |
| L2 Cache | 16 MB |
| Socket | SP3 (LGA 4094) |
| PCI Express Support | PCIe 4.0 x128 lanes |
| Memory Support | 8-channel DDR4 ECC Registered / RDIMM / LRDIMM |
| Max Memory Speed | DDR4-3200 MT/s |
| Thermal Design Power (TDP) | 200 W |
| Supported Technologies | SMT (Simultaneous Multithreading), AVX2, AES-NI, Secure Memory Encryption (SME), Secure Encrypted Virtualization (SEV) |
| Target Use Cases | Enterprise servers, virtualization, cloud computing, HPC, database environments |
Supermicro H12SSL-i ：
| Category | Specification |
|---|---|
| Model | Supermicro H12SSL-i |
| Form Factor | ATX (12" x 9.6") |
| CPU Support | AMD EPYC™ 7002 / 7003 Series (Rome / Milan) |
| Socket | SP3 |
| Chipset | SoC (System on Chip, integrated in CPU) |
| Memory Type | DDR4 ECC Registered (RDIMM / LRDIMM) |
| Memory Slots | 8x DIMM |
| Max Memory Capacity | Up to 2TB |
| Memory Speed | Up to DDR4-3200 (depends on CPU) |
| Memory Channels | 8-Channel |
| Expansion Slots | 1x PCIe 4.0 x161x PCIe 4.0 x8 (in x16 slot)1x PCIe 4.0 x8 |
| Storage Interface | 8x SATA3 (6Gb/s)1x M.2 (PCIe 4.0 x4 / SATA3) |
| LAN | 2x Intel i210-AT Gigabit Ethernet ports |
| Management LAN | 1x Dedicated IPMI 2.0 LAN port |
| Video | ASPEED AST2500 BMC (VGA output) |
| Rear I/O Ports | 2x USB 3.1 Gen12x USB 2.0VGA3x LAN (2 data + 1 management) |
| Internal I/O | USB headers, TPM header |
| Management Features | IPMI 2.0, KVM-over-LAN, Virtual Media |
| Power Connectors | 24-pin ATX + 8-pin CPU |
| Operating Temperature | 10°C – 35°C (50°F – 95°F) |
| Dimensions | 12" x 9.6" (ATX) |
