Product List
Supermicro H11SSL-i Motherboard * 1AMD EPYC 7402P * 1
Product Specifications
Supermicro H11SSL-i Motherboard：| Category | Specification |
|---|---|
| CPU Support | Single AMD EPYC™ 7001 / 7002 Series Processor (EPYC 7002 requires board revision 2.x) |
| Memory Support | • Up to 2.1TB Registered ECC DDR4-2666 MHz (8 DIMMs) • Up to 2TB Registered ECC DDR4-3200 MHz (8 DIMMs, board revision 2.x required) |
| Expansion Slots | • 3 × PCI-E 3.0 x16 • 3 × PCI-E 3.0 x8 |
| M.2 Interface | • 1 × PCI-E 3.0 x4 • Form Factor: 2280 / 22110 • Key: M-key |
| Storage | 16 × SATA3 ports + 1 × M.2 |
| Network | Dual Gigabit Ethernet LAN |
| Graphics | ASPEED AST2500 BMC |
| USB Ports | • Up to 5 × USB 3.0 (2 rear + 2 via header + 1 Type-A) • Up to 4 × USB 2.0 (2 rear + 2 via header) |
| Cooling / Fan Headers | 7 × PWM 4-pin Fan Headers with tachometer monitoring |
AMD EPYC 7402P：
| Specification | Details |
|---|---|
| Model | AMD EPYC 7402P |
| Architecture | Zen 2 (Rome) |
| Platform / Socket | SP3 |
| Cores / Threads | 24 Cores / 48 Threads |
| Base Clock | 2.8 GHz |
| Max Boost Clock | 3.35 GHz |
| L3 Cache | 128 MB |
| TDP | 180 W |
| PCIe Version | PCIe 4.0 |
| Memory Support | DDR4 |
| Memory Channels | 8-Channel |
| Max Memory Speed | Up to DDR4-3200 |
| Manufacturing Process | 7 nm |
| Supported Technologies | AMD Infinity Fabric, Secure Memory Encryption (SME), Secure Encrypted Virtualization (SEV) |
| P-Series Note | Single-socket optimized (better price/performance for 1P systems) |
| Typical Use Cases | Servers, Virtualization, Cloud Computing, HPC |
