Product List
GIGABYTE MZ31-AR0 * 1AMD EPYC 7571 *1
Product Specifications
AMD EPYC 7571：| Specification | Details |
|---|---|
| Brand | AMD |
| Processor Model | AMD EPYC 7571 |
| Part / Stepping Code | PXXXXXXXXXXXXF |
| Cores / Threads | 32 Cores / 64 Threads |
| Base Clock | 2.20 GHz |
| Maximum Boost Clock | Up to 3.00 GHz |
| L3 Cache | 64 MB |
| Architecture Codename | Naples |
| Microarchitecture | 1st Gen Zen |
| Memory Support | DDR4 |
| Maximum Memory Speed | Up to 2666 MT/s |
| TDP | 120 W |
| CPU Socket | SP3 |
| Manufacturing Process | 14 nm |
Gigabyte MZ31-AR0:
| Item | Specification |
|---|---|
| Model | GIGABYTE MZ31-AR0 |
| Revision | Rev. 2.x |
| Form Factor | E-ATX |
| Dimensions | 305 × 330 mm |
| CPU Support | AMD EPYC 7002 Series Processors |
| CPU Socket | SP3 |
| Processor Support | Single Processor |
| Chipset | System on Chip |
| Memory Type | DDR4 RDIMM / LRDIMM |
| Memory Slots | 16 DIMM Slots |
| Memory Channels | 8-Channel Memory Architecture |
| Memory Speed | Up to DDR4-3200* |
| LAN | 2 × SFP+ 10Gb/s LAN ports |
| Management LAN | 1 × Dedicated Management Port |
| Graphics | Aspeed AST2500 Integrated Graphics |
| Storage Interface | 4 × SlimSAS |
| SATA Support | Up to 16 × SATA III 6Gb/s Ports |
| M.2 Slot | 1 × M.2 (M-key, PCIe Gen3 x4) |
| Expansion Slots | Up to 4 × PCIe Gen3 x16 and 3 × PCIe Gen3 x8 |
| Rear I/O | 2 × USB 3.0, 2 × USB 2.0, 1 × VGA, 1 × COM, 2 × SFP+, 1 × MLAN |
| TPM | 1 × TPM Header |
| Remote Management | Aspeed AST2500 / GIGABYTE Management Console |
| Use Case | AMD EPYC UP Server M |
