Product List
HUANANZHI H12D-8D*1
AMD EPYC 7F52 *1
Product Specifications
HUANANZHI H12D-8D：
| Category | Details |
|---|---|
| Product Model | Huanan Gold H12D-8D |
| Supported CPU | AMD EPYC 7002 (Rome) / 7003 (Milan) Series |
| Memory Slots | 8 x DDR4 DIMM SlotsSupports 8-channel DDR4 3200/2933/2666/2400/2133 MHzMax Capacity: 2TB (depends on CPU) |
| Storage Interfaces | - 4 x SATA 3.0 (6Gbps)- 3 x SFF-8643 (expandable to 12 x SATA 3.0)- 3 x PCIe 4.0 x4 U.2 NVMe |
| PCIe Slots | 4 x PCIe 4.0 x16 Slots |
| Onboard LAN | - 2 x Intel I226V 2.5G Ethernet- 1 x IPMI port (requires BMC module)- Realtek RTL8201F |
| M.2 Slots | 3 x M.2 2280 NVMe PCIe 4.0 x4 |
| Audio Codec | CJC6811A |
| PCB Layers | 14-Layer PCB |
| Power Phases | 9+5 Phase DrMOS Power (60A) |
| Rear I/O Ports | - 4 x USB 3.2 Gen1- 2 x USB 2.0- 3 x RJ45 LAN Ports- 1 x 2-channel Audio Jack- 1 x VGA Port (BIC module required) |
| Front Panel Headers | - 1 x USB 3.2 Gen1 Header- 1 x USB 2.0 Header- 1 x Audio H eader- 1 x COM Header- 1 x SM Bus Header- 1 x NCSI Header- 1 x System Reset Header- 1 x PMBus Header- 1 x MB_BIOS Header- 1 x DEBUG Header |
| Form Factor | 305 × 245 mm (ATX) |
| Management | ASPEED AST2500 BMC (optional module), supports IPMI 2.0 |
AMD EPYC 7F52
