Zrontech – High Performance Components
Please note: Buyers are responsible for customs and duties. EU orders over 150€ may incur VAT on delivery; under 150€ VAT is collected on eBay. All products are genuine and tested; a test video is recorded. Actual delivery may vary based on stock.
Product List
AMD EPYC 7402P * 1Supermicro H11SSL-i * 1
Product Specifications
AMD EPYC 7402P :| Specification | Details |
|---|---|
| Processor Model | AMD EPYC 7402P |
| Product Family | AMD EPYC 7002 Series |
| Architecture | Zen 2 (Rome) |
| Socket | SP3 |
| Cores | 24 |
| Threads | 48 |
| Base Clock | 2.80 GHz |
| Max Boost Clock | Up to 3.35 GHz |
| L3 Cache | 128 MB |
| Manufacturing Process | 7 nm |
| TDP | 180 W |
| Memory Type | DDR4 |
| Memory Channels | 8 Channels |
| Maximum Memory Speed | DDR4-3200 |
| ECC Memory Support | Yes |
| PCI Express Version | PCIe 4.0 |
| PCIe Lanes | Up to 128 |
| Socket Count | 1P / Single Socket |
| Unlocked Multiplier | No |
| Integrated Graphics | No |
| Application | Server / Workstation |
| Launch Generation | 2nd Gen AMD EPYC |
Supermicro H11SSL-i :
| Specification | Details |
|---|---|
| Model | Supermicro H11SSL-i Rev 2.x |
| Form Factor | ATX |
| Dimensions | 12" × 9.6" (30.5 × 24.4 cm) |
| CPU Socket | Socket SP3 |
| CPU Configuration | Single Socket |
| Supported CPUs | AMD EPYC 7001 / 7002 Series |
| Maximum CPU Cores | Up to 64 Cores with Rev 2.x |
| Chipset | System on Chip (SoC) |
| Memory Slots | 8 × DIMM Slots |
| Maximum Memory | Up to 2TB ECC DDR4 |
| Memory Type | DDR4 Registered ECC |
| Memory Speed | Up to DDR4-3200 MHz with Rev 2.x |
| Memory Channels | 8-Channel |
| DIMM Sizes | 8GB / 16GB / 32GB / 64GB / 128GB / 256GB |
| Memory Voltage | 1.2V |
| ECC Support | Yes |
| SATA | 16 × SATA III 6Gb/s |
| PCI Express Slots | 3 × PCIe 3.0 x16, 3 × PCIe 3.0 x8 |
| M.2 Interface | PCIe 3.0 x4 |
| M.2 Form Factor | 2280 / 22110 |
| M.2 Key | M-Key |
| LAN | 2 × RJ45 Gigabit Ethernet |
| LAN Controller | Intel I210 |
| IPMI LAN | 1 × Dedicated RJ45 |
| IPMI | IPMI 2.0 with KVM over LAN |
| BMC | ASPEED AST2500 |
| VGA | 1 × VGA Port |
| USB 3.0 | 5 Ports |
| USB 2.0 | 4 Ports |
| COM Port | 1 × Rear COM Port |
| TPM | 1 × TPM 2.0 Header |
| SATA DOM Power | 2 × Connectors |
| BIOS | AMI 128Mb SPI Flash EEPROM |
| Fan Support | Up to 7 Fans with PWM Control |
| Hardware Monitoring | CPU Voltage, Fan Speed, Temperature |
| Operating Temperature | 10°C to 35°C (50°F to 95°F) |
| Non-Operating Temperature | -40°C to 70°C (-40°F to 158°F) |
| Operating Humidity | 8% to 90% RH, Non-Condensing |
| Target Application | Server / Workstation |
