Product List
AMD EPYC 7551 CPU *2Supermicro H11DSi E-ATX Motherboard*1
Product Specifications
AMD EPYC 7551:| Specification | Details |
|---|---|
| Processor Model | AMD EPYC 7551 |
| Product Family | AMD EPYC 7001 Series |
| Architecture | Zen |
| Socket | SP3 |
| Cores | 32 |
| Threads | 64 |
| Base Clock | 2.00 GHz |
| Max Boost Clock | Up to 3.00 GHz |
| L3 Cache | 64 MB |
| Lithography | 14 nm |
| TDP | 180 W |
| Memory Type | DDR4 ECC |
| Memory Channels | 8 Channels |
| Maximum Memory Speed | DDR4-2666 MHz |
| PCI Express Version | PCIe 3.0 |
| PCIe Lanes | 128 |
| Supported Configuration | 1P / 2P |
| ECC Support | Yes |
| SMT Support | Yes |
| Virtualization Support | AMD-V |
| Target Application | Server / Data Center |
Supermicro H11DSi :
| Specification | Details |
|---|---|
| Model | Supermicro H11DSi |
| Form Factor | E-ATX |
| Dimensions | 12" × 13.05" (30.5 × 33.1 cm) |
| CPU Socket | Dual Socket SP3 |
| Supported CPUs | AMD EPYC 7001 / 7002 Series Processors |
| Maximum CPU TDP | Up to 240W |
| Maximum Cores | Up to 32 Cores per CPU |
| Maximum Total Cores | Up to 64 Cores with Dual CPUs |
| Chipset | System on Chip (SoC) |
| Memory Slots | 16 × DDR4 DIMM Slots |
| Memory Capacity | Up to 2TB ECC DDR4 |
| Memory Channels | 8-Channel Memory Architecture |
| Memory Type | ECC DDR4 RDIMM / LRDIMM |
| Memory Speed | Up to DDR4-2666 MHz |
| Rev. 2.x Memory Support | Up to DDR4-3200 MHz |
| DIMM Capacities | 8GB / 16GB / 32GB / 64GB / 128GB / 256GB* |
| Memory Voltage | 1.2V |
| ECC Support | Yes |
| SATA | 10 × SATA III 6Gb/s Ports |
| PCI Express | 3 × PCIe 3.0 x8, 2 × PCIe 3.0 x16 |
| M.2 Interface | 1 × SATA / PCIe 3.0 x2 |
| M.2 Form Factors | 2280 / 22110 |
| M.2 Key | M-Key |
| LAN | 2 × RJ45 Gigabit Ethernet |
| LAN Controller | Intel i350-AM21 |
| IPMI LAN | 1 × Dedicated RJ45 IPMI Port |
| IPMI | IPMI 2.0 with KVM over LAN |
| BMC Controller | ASPEED AST2500 |
| Graphics | ASPEED AST2500 BMC Integrated Graphics |
| VGA | 1 × VGA Port |
| USB 3.0 | 2 × Rear USB 3.0 Ports |
| USB 2.0 | 4 × USB 2.0 Ports (2 Rear + 2 Headers) |
| COM Port | 1 × Rear COM Port |
| TPM | 1 × TPM 1.2 Header |
| BIOS Type | AMI 128Mb SPI Flash EEPROM |
| BIOS Features | Plug and Play (PnP), DMI 2.3, PCI 2.2, ACPI 5.1, USB Keyboard Support, SMBIOS 3.1.1 |
| Hardware Monitoring | CPU Voltage, System Voltage, Fans, Temperature |
| Fan Monitoring | Up to 8 Fans |
| Fan Control | PWM Fan Speed Control |
| Temperature Monitoring | CPU and System Temperature Monitoring |
| Chassis Intrusion | Supported |
| UID | Supported |
| Operating Temperature | 10°C to 35°C (50°F to 95°F) |
| Non-Operating Temperature | -40°C to 70°C (-40°F to 158°F) |
| Operating Humidity | 8% to 90% RH, Non-Condensing |
| Non-Operating Humidity | 5% to 95% RH, Non-Condensing |
