Product List
ASUS ROG STRIX TRX40-XE * 1AMD Ryzen Threadripper 3970X *1
Product Specifications
AMD Ryzen Threadripper 3970X：| Specification | Details |
|---|---|
| Processor Model | AMD Ryzen Threadripper 3970X |
| Market Segment | High-End Desktop (HEDT) |
| Architecture | Zen 2 |
| CPU Cores | 32 |
| CPU Threads | 64 |
| Base Clock | 3.70 GHz |
| Max Boost Clock | Up to 4.50 GHz |
| Total Cache | 144 MB |
| L2 Cache | 16 MB |
| L3 Cache | 128 MB |
| Manufacturing Process | TSMC 7 nm |
| CPU Socket | sTRX4 |
| Default TDP | 280 W |
| Memory Type | DDR4 |
| Maximum Memory Speed | DDR4-3200 |
| Memory Channels | 4 Channels |
| PCI Express Version | PCIe 4.0 |
| PCIe Lanes | 88 Total / 72 Usable |
| Integrated Graphics | No |
| Unlocked for Overclocking | Yes |
| Launch Date | November 2019 |
ASUS ROG STRIX TRX40-XE GAMING：
| Specification | Details |
|---|---|
| Model | ASUS ROG STRIX TRX40-XE GAMING |
| CPU Socket | AMD Socket sTRX4 |
| Supported Processors | 3rd Gen AMD Ryzen Threadripper Desktop Processors |
| Maximum CPU Cores | Up to 64 Cores |
| Chipset | AMD TRX40 |
| Memory Slots | 8 × DDR4 DIMM Slots |
| Maximum Memory | Up to 256GB |
| Memory Architecture | Quad-Channel Memory Architecture |
| Memory Type | ECC and Non-ECC Unbuffered DDR4 Memory |
| Memory Speeds | DDR4 4666(O.C.) / 4600(O.C.) / 4400(O.C.) / 4333(O.C.) / 4266(O.C.) / 4133(O.C.) / 3800(O.C.) / 3733(O.C.) / 3466(O.C.) / 3400(O.C.) / 3200 / 2800 / 2666 / 2400 / 2133 MHz |
| Multi-GPU Support | NVIDIA 2-Way SLI and AMD 2-Way CrossFireX |
| PCIe Expansion Slots | 3 × PCIe 4.0 x16 Slots |
| Additional Expansion Slot | 1 × PCIe 4.0 x4 Slot |
| M.2 Storage | 3 × M.2 Socket 3 Slots |
| M.2 Device Support | 2242 / 2260 / 2280 / 22110 |
| M.2 Interface | PCIe 4.0 x4 and SATA Modes |
| SATA Ports | 8 × SATA 6Gb/s Ports |
| RAID Support | RAID 0, RAID 1 and RAID 10 |
| Primary LAN | Realtek RTL8125-CG 2.5Gb Ethernet |
| Secondary LAN | Intel I211-AT Gigabit Ethernet |
| LAN Features | ROG GameFirst V and ASUS LANGuard |
| Wireless Network | Intel Wi-Fi 6 AX200 |
| Wi-Fi Standard | IEEE 802.11a/b/g/n/ac/ax |
| Wi-Fi Frequency | Dual-Band 2.4GHz and 5GHz |
| Wi-Fi Configuration | 2 × 2 MU-MIMO |
| Maximum Wi-Fi Speed | Up to 1.73Gbps |
| Bluetooth | Bluetooth 5.0 |
| Audio Codec | ROG SupremeFX S1220 8-Channel HD Audio Codec |
| Audio Playback | Up to 32-Bit / 192kHz |
| Audio Signal-to-Noise Ratio | 120dB Playback / 108dB Recording |
| Audio Features | Sonic Studio III, Sonic Radar III, DTS Sound Unbound and Dual Operational Amplifiers |
| Rear USB 3.2 Gen 2 | 8 Ports: 7 × Type-A and 1 × Type-C |
| Rear USB 2.0 | 4 × USB 2.0 Ports |
| Front USB 3.2 Gen 2 | 1 × Front-Panel Connector |
| Front USB 3.2 Gen 1 | 2 × Headers Supporting 4 Ports |
| Internal USB 2.0 | 2 × Headers Supporting 4 Ports |
| Rear Network Ports | 1 × 2.5Gb RJ45 and 1 × Gigabit RJ45 |
| Rear Audio Ports | 5 × Audio Jacks |
| Optical Audio Output | 1 × Optical S/PDIF Output |
| BIOS Flashback | Dedicated USB BIOS Flashback Button |
| Main Power Connector | 1 × 24-Pin EATX Connector |
| CPU Power Connectors | 2 × 8-Pin ATX 12V Connectors |
| CPU Fan Headers | 1 × CPU Fan and 1 × CPU Optional Fan Header |
| Chassis Fan Headers | 3 × Chassis Fan Headers |
| Water Cooling Headers | 1 × AIO Pump and 1 × W_PUMP+ Header |
| Additional Fan Headers | Chipset Fan and VRM Heatsink Fan Headers |
| RGB Headers | 2 × Aura RGB Headers |
| Addressable RGB Headers | 2 × Gen 2 Addressable Headers |
| TPM Header | Supported |
| Front-Panel Audio | 1 × AAFP Connector |
| Temperature Sensor | 1 × Temperature Sensor Header |
| Diagnostic Features | Q-LED for CPU, DRAM, VGA and Boot Device |
| Onboard Display | 1.3-Inch LiveDash OLED |
| Onboard Controls | Power Button and Clear CMOS Header |
| I/O Shield | Pre-Installed Rear I/O Shield |
| BIOS | 128Mb Flash ROM, UEFI AMI BIOS |
| BIOS Standards | PnP, WfM 2.0, SMBIOS 3.2 and ACPI 6.2 |
| Supported Operating System | Windows 10 64-Bit |
| Form Factor | ATX |
| Dimensions | 12 × 9.6 Inches / 30.5 × 24.4cm |
