Product List
HUANANZHI H12D-8D*1
AMD EPYC 7452 *1
Product Specifications
AMD EPYC 7452 Processor Specifications
| Category | Specifications |
|---|---|
| Processor Model | AMD EPYC™ 7452 |
| Processor Family | AMD EPYC™ 7002 Series (Rome) |
| CPU Cores | 32 Cores |
| CPU Threads | 64 Threads |
| Base Clock Speed | 2.35 GHz |
| Max Boost Clock Speed | Up to 3.35 GHz |
| L3 Cache | 128 MB |
| Default TDP | 155W |
| Memory Support | 8-Channel DDR4 Memory |
| Maximum Memory Speed | DDR4-3200 MHz (1DPC) |
| Memory Bandwidth | Up to 205 GB/s Theoretical Bandwidth |
| PCI Express Support | PCIe 4.0 |
| PCIe Lanes | 128 PCIe 4.0 Lanes |
| Socket Compatibility | Socket SP3 |
| Target Applications | Enterprise Servers, Workstations, Virtualization, AI Computing, Data Processing |
Motherboard Specifications – HUANANZHI H12D-8D
| Category | Specifications |
|---|---|
| Product Model | HUANANZHI H12D-8D (Huanan Gold Series) |
| Form Factor | ATX Form Factor, 305 × 245 mm |
| CPU Support | Supports AMD EPYC™ 7002 (Rome) / 7003 (Milan) Series Processors |
| CPU Socket | Dual Socket SP3 Platform |
| Chipset / Platform | AMD EPYC Server Platform |
| Memory Slots | 8 × DDR4 DIMM Slots |
| Memory Type | DDR4 ECC Registered Memory (RDIMM) |
| Memory Architecture | 8-Channel Memory Architecture |
| Maximum Memory Capacity | Up to 2TB (Depending on CPU Configuration) |
| Supported Memory Speed | DDR4 3200 / 2933 / 2666 / 2400 / 2133 MHz |
| Storage Interface | 4 × SATA III (6Gb/s) Ports |
| SFF-8643 Interface | 3 × SFF-8643 Connectors (Expandable up to 12 × SATA III Drives) |
| U.2 Storage Support | 3 × PCIe 4.0 x4 U.2 NVMe Interfaces |
| M.2 Slots | 3 × M.2 2280 NVMe PCIe 4.0 x4 Slots |
| PCIe Expansion Slots | 4 × PCIe 4.0 x16 Slots |
| LAN Controller | 2 × Intel® I226V 2.5Gb Ethernet |
| Additional Network Interface | 1 × IPMI Dedicated LAN Port (Requires BMC Module) |
| Management Controller | ASPEED AST2500 BMC (Optional), Supports IPMI 2.0 |
| Additional LAN Chip | Realtek RTL8201F |
| Audio Codec | CJC6811A |
| PCB Design | 14-Layer PCB |
| Power Design | 9+5 Phase DrMOS Power Design (60A) |
| Rear I/O Ports | 4 × USB 3.2 Gen1 Ports |
| Rear USB Ports | 2 × USB 2.0 Ports |
| Rear Network Ports | 3 × RJ45 LAN Ports |
| Video Output | VGA Port (Requires BIC Module) |
| Audio Output | 2-Channel Audio Jack |
| Front Panel Headers | USB 3.2 Gen1 Header ×1 |
| Front Panel Headers | USB 2.0 Header ×1 |
| Front Panel Headers | Audio Header ×1 |
| Front Panel Headers | COM Header ×1 |
| Front Panel Headers | SMBus Header ×1 |
| Front Panel Headers | NCSI Header ×1 |
| Front Panel Headers | System Reset Header ×1 |
| Front Panel Headers | PMBus Header ×1 |
| BIOS / Debug Features | MB_BIOS Header ×1, DEBUG Header ×1 |
