Welcome to intercooler_topseller~

Note: Pls check the item pictures and sizes to get the suitable item.

Package included:

1 X 4-ROW Aluminum Radiator
1 X Aluminum Shroud

2 X 14"Fan

Radiator Configuration:
High Performance Racing Spec.
4-Row of tubes Core Racing Design
Material: Aluminum
Core Size: 30 1/2"WIDTH x 17" HEIGHT
Overall size: 36" WIDTH x 18 5/8" HEIGHT
Tanks Sizes: 2 3/4 x 18 5/8
Inlet Hose Connection: 1 1/2" Driver Side
Outlet Hose Connection: 1 1/2 "Passenger Side
Transmission Oil Cooler: Yes Passenger Side

Engine Oil Cooler: Yes Driver Side

FITMENT:
1994-1996 CHEVY IMPALA 5.7L
1994-1996 CHEVY CAPRICE 5.7L
1994-1996 CADILLAC FLEETWOOD 5.7L
1994-1996 BUICK ROADMASTER 5.7L

Fan Specification:
Diameter : 14'' (Blade to Blade)
Voltage: DC 12 Volts
Wattage: 90W
Number of Blades: 8 S-Type blades
Maximum Fan CFM（Cubic Feet per Minute）: 2250cfm
Maximum Fan RPM（Revolution(s) Per Minute）: 2000±10%
Fan Thickness: 2.64"
S-Type Blade pull push design, to make air flow more efficient and bring more cooling Effect
Powerful 90 watt motor will keep your engine cool.

Description:
This aluminum radiator is designed to provide maximum cooling efficiency to prevent premature engine failure. Its light-weight, and high-heat transferring aluminum features a tube and fin design that, dramatically increases surface area that enables the heat to dissipate more efficiently. This Aluminum Radiator is at least 40% more efficient than stock ones. Most importantly, it has a much higher capacity for coolant than stock ones, which means that your cooling system will be more efficient and will be more resistant to temperature surges in racing applications.

Aluminum Shroud+Fan:
The fan and the fan shroud effectively drive the heat over and out the engine compartment rather than thrusting it into the front of the engine. The fan shroud basically houses the fan blades securing it in place and keeping it from damaging the other engine components that may disturb the smooth and even operation of the engine. With excellent operating temperature management, allowable levels of engine temperature are stabilized. Investing in proper maintenance though will considerably benefit the ride and driving quality in maintaining the ideal working conditions of the engine.
