1080P HD Mini 2.4MP 4 in 1 HD AHD/CVI/TVI/CVBS Analog weatherproof Small Bullet Camera
***NO IR(NO Infrared)****
Features:
- 1/3" IMX323 HD CMOS
- Resolution 2Megapixel
- 2.8mm board lens, view angle of 90 degree
- DC 12V Power input (Power Adapter Not Included)
- BNC Video output
Specification:
|
Model |
|
|
Image Sensor |
1/3" IMX323 CMOS |
|
DSP |
IMX323 |
|
Horizontal Resolution |
2.4 Mega Pixel 1080P AHD CVI TVI CVBS 4 -In-1 |
|
Effective Pixel |
PAL : 1920X1080@25fps |
|
NTSC : 1920X1080@30fps |
|
|
Min. Illumination |
0.01 Lux (F1.2) |
|
Signal System |
NTSC/PAL |
|
Electronic Shutter |
PAL:1/50~1/100000s;NTSC:1/60~1/100000s |
|
Max Transmission Distance |
Common 75-3 lines can be up to 500m |
|
Lens size |
2.8mm board lens |
|
S/N Ratio |
More than 46dB |
|
Gamma |
0.45/1.0 |
|
Exposure |
Auto |
|
|
|
|
Sync. System |
Internal |
|
Audio Output |
Optional |
|
Video Output |
1 Vp-p / 75 Ohms |
|
Working Conditions |
-20~60Degree |
|
Power Supply |
DC12V/75MA |
|
Size |
20X75mm |
Package:
- 1x 2.4MP 4 in 1 Mini Camera
- 1X small Bracket
