| General Features |
| DIN Size | 1 DIN |
| Detachable Faceplate | Yes |
| Key Illumination | Red LED |
| Rotary Encoder & Control Knob | Yes |
| Dual Accent Key | Handsfree & Audio Streaming |
| Back-up Memory | Menu Settings |
| Touch Sensor Tone | Yes |
| Digital Clock (24H) | Yes |
| Clock display when power-off | default off |
| All-off Select (20/40/60 minutes) | Yes |
| Built-in Connector | Mitsumi, 16 pin |
| ISO connector | Yes, Mitsumi to ISO cable |
| Bluetooth unit built-in | Yes |
| USB interface x 1 | Yes |
| Firmware upgreadable | Yes |
| Mechless receiver | Yes |
| Short body | Yes |
| |
| Display Type | Liquid Crystal Display (LCD) |
| Display Layout | 1 line 13 Segments x 13 Digit |
| Vertical Aligment Liquid Crystal Display | Yes |
| Display Illumination | White (LED) |
| Dimmer Control | Manual / Set by Timer |
| Brightness control | 0 - 31 steps |
| Demo Mode | Yes |
| Menu text in selectable language | English(default) / Spanish / French / Russian |
| TAG Language Display | English, Spanish, Russian & Greek |
| |
| Front/edge | Black Injection |
| Dress plate | Black Injection |
| Preset key finish | Black Injection |
| Escutcheon finish | Black Injection |
| Triangle Illumination | Red LED |
| Front terminals dust cover | Yes |
| Key illumination | Red LED |
| Illuminated front USB port | Red LED |
| Display illumination | White LED |
| Brightness Control (Key) | 0 - 31 step |
| Brightness Control (Display) | 0 - 31 step |
| Dimmer Control (Key) | Manual / Set by Timer |
| Dimmer Control (Display) | Manual / Set by Timer |
| |
| Station Select | Manual / Preset |
| Tuner preset/recall key | Yes |
| FM Reception | Yes |
| AM (MW/LW) Reception | Yes |
| Tuner Presets (FM/AM) | 24 Presets (18FM / 6AM) |
| Preset memory w/o back-up power | Yes |
| Mixed preset memory (FM & AM) | 6 presets |
| Tuning mode | Auto1/Auto2/Manual |
| Up/Down Seek/Scan | Yes |
| Automatic Memory Entry (AME) | Yes |
| FM Stereo / Mono Selector | Yes |
| Radio Data System | Yes |
| Radio Text Plus | Yes |
| Traffic Information | Yes |
| Local search | Yes |
| AF Regional | Selectable: AF/AF Reg/OFF |
| Auto TP search | Yes |
| Enhanced Other Networks Function (EON) | Yes |
| Program Type Function (PTY) | Yes |
| |
| DAB+ tuner built-in | Yes |
| Digital Radio Certification Mark | Yes |
| Intelligent seek | Yes, (Service, Ensemble & Component) |
| Tuning mode / Seek mode | Auto1/Auto2/Manual |
| Service preset | 6 ch * 3 bank presets, |
| Service list by alphabet order | Yes |
| Preset list | Yes |
| Alphabet Search | Yes |
| Related service | Yes |
| Audio interrupt standby by PTY | Yes |
| Audio interrupt standby by announcement | Yes |
| DAB-RDS integrated TI | Yes |
| Traffic Information | Yes |
| DAB priority | Yes |
| PTY (Programme Type) search | Yes |
| PTY (Programme Type) watch | Yes |
| Soft linking | Yes |
| Antenna power supply on/off switch | Yes |
| DAB antenna included | Yes, SMB terminal |
| |
| MP3 files are playable | USB |
| WMA (.wma) files are playable | USB |
| WAV (.wav) files are playable | USB |
| FLAC files are playable | USB |
| |
| USB terminal | Yes, Front with dust cover |
| USB Type | USB 1.1/USB 2.0 Full Speed |
| Drive Change | Yes |
| WMA (Windows Media File) playback | Yes |
| WAV (Waveform Audio Format) playback | Yes |
| FLAC (Free Lossless Audio Codec) playback | Yes |
| Repeat / Random Play | Yes |
| Resume play | Yes |
| Time code display | Yes |
| 1,5A Smartphone Quick Charge | Yes |
| |
| Maximum Output Power | 50W x 4 |
| MOSFET Power IC | Yes |
| Auxiliary input | Yes, Front, Mini-jack |
| Pre-out | 1 RCA |
| Pre-out Output Level | 2.5V |
| Preout Rear / Subwoofer Switchable | Yes |
| Subwoofer Reference Level Adj. | Yes |
| 2-Way X'over network | Yes |
| 3-Way x'over (bi-amp connection) | Yes |
| Balance/Fader/Loudness Control | Yes |
| Loudness Control | Off / LV1/ LV2 |
| Bass Boost Circuit | Off/+1/+2/+3/+4/+5 |
| Graphic Equalizer + Preset | 13-Bands Graphic Equalizer with 8 Presets. |
| Digital Sound Processor (DSP) Built-in | Yes |
| Digital Time Aligment (DTA) | Yes |
| Low- & High-pass Filter | Yes |
| Speaker Size Control | Yes |
| Sound Reconstruction | Yes |
| Space Enhancer | Yes |
| Realizer | Yes |
| Stage EQ | Yes |
| Drive EQ | Yes |
| Sound Elevation | Yes |
Bluetooth General Features |
| Max num. of regist. phones for HFP & A2DP | 5 phones |
| Hands Free Profile with High Sound Quality | HFP V1.7.1 |
| 2 phones fulltime connection | Yes |
| High Quality Audio Streaming | SBC |
| Serial Port Profile (SPP) | Yes |
| Phonebook Access Profile (PBAP) | Yes |
| Easy pairing function | Yes |
| Android automatic pairing via USB | Yes |
| KENWOOD Remote App Ready | Android only, available in Play store |
| KENWOOD Music Mix Support | Yes |
| Private mode | Yes |
| Interrupt call request | Yes |
| Alphabet Search (Phonebook) | Yes |
| Voice Control | Yes |
| Phone device status display | Yes |
| Audio device status display | Yes |
| Signal strength display | Yes |
| Remaining battery display | Yes |
| Bluetooth Paring Indicator | Yes |
| High-quality noise canceling microphone | Included (rear wired) |
| Bluetooth firmware upgradeable | Yes, Included in system updates |
| * depends on phone model/make | & Kenwood unit |
| |
| Front USB & AUX Input | Yes |
| OEM Wired Remote Control ready | Yes, Optional interface needed |
| DC-Cord | NEW Mitsumi to ISO |
| Power Control (P.CON) wire | Yes |
| 2-way (Tel/Navi) mute wire | Yes |
| FM Antenna Input | |
| DAB Aerial input | SMB connector |
| External microphone input | 3,5mm mini-jack |
| |
| FM range: 87.5Mhz - 108MHz (50Khz step) | Yes |
| FM Usable Sensitivity | 0.56μV/75ohm (S/N 30dBf) |
| FM Quieting Sensitivity | 1.58μV/75ohm (S/N 46dBf) |
| FM Frequency Response | 30Hz ~ 15kHz (± 3dB) |
| FM Signal to noise ratio (Mono) | 68dB |
| FM Stereo Separation (1kHz) | 40dB |
| MW range: 531kHz - 1611kHz (9kHz step) | Yes |
| MW Usable Sensitivity | 28.5μV |
| LW range: 153kHz - 279kHz (9kHz step) | Yes |
| LW Usable Sensitivity | 45μV |
| |
| Band III - Frequency range | 174.928 MHz - 239.2MHz |
| Mode | I, II, III, IV |
| Sensitivity | - 100dBm |
| Signal to noise ratio | 90dB |
| DAB Aerial Connector Type | SMB |
| Output Voltage | 12V (11V to 16V allowable) |
| Maximum Current | < 100 mA |
| |
| USB Version compatibility | USB 1.1 / 2.0 full speed |
| File System | FAT 32 / 16 / 12 |
| Maximum Supply current | 1500mA |
| MP3 Decode | Compliant with MPEG-1/2 Audio Layer-3 |
| WMA Decode | Compliant with Windows Media Audio |
| WAV Decode | Linear - PCM Files |
| flac Decode | FLAC files up to 96kHz/24bit |
| Frequency Response | 20Hz - 20kHz |
| S/N Ratio | 99 dB (1kHz) |
| Dynamic Range | 93dB |
| Channel Separation | 90dB |
| |
| Maximum Power | 50W x 4 |
| Output Power (DIN45324,+B=14.4v) | 22W x 4 |
| Preout Level | 2500mV / 10kOhm, |
| Preout Impedance | ≤ 600Ohm |
| Speaker Impedance | 4Ohm ~ 8Ohm |
| AUX Frequency Response | 20Hz ~ 20kHz (±1dB) |
| AUX Maximum Input Voltage | 1000mV |
| AUX Input Impedance | 30kOhm |
| Graphical Equalizer | 13-Band |
| G. EQ. Frequency (Hz) | 62,5/100/160/250/400/630/1k/1k6/2k5/4k/6k3/10k/16k |
| G. EQ. Gain (dB) | -7 / ... / +7 |
| Subwoofer Level (dB) | -50 dB to +10dB |
| |
| Technology | Bluetooth V4.2 |
| Frequency | 2.402 - 2.48 GHz |
| Output power | +4dBm(max), power class 2 |
| Maximum range | Line of sight approx. 10 meter |
| Handsfree profile (HFP) | Yes, V1.7.1 |
| Serial port profile (SPP) | Yes |
| Advanced audio distribution profile (A2DP) | Yes |
| Audio Codec | SBC |
| Audio/Video remote control profile (AVRCP) | Yes, V1.6.1 |
| Phonebook access profile (PBAP) | Yes |
| |
| Release keys | 2 pieces |
| Escutcheon | Yes |
| Installation Sleeve | Yes |
| DC cord (Mitsumi to ISO) | 20 cm |
| DAB antenna | with 3 m cable |
| Handsfree Microphone | with 3 m cable |
| Multi-Language Instruction Manual Included | Quick-Guide |
| Manuals Downloadable | Yes |
| |
| Operating voltage | 14.4V (10.5 ~ 16V Allowable) |
| Maximum Current Consumption | 10A |
| Dimensions (WxHxD) | 182 x 53 x 100mm |
| Weight | 700 gr. |
