Product Type: Generator |
Replaces: 103678502 3008369B 3102201HI1 30083-69E 30083-69C G096503 G338771 |
  • Amperage: 25 |
  • Rotation: Reversible |
  • Volts: 12 |
  • Source: Aftermarket
Over 30,000 aftermarket & original parts
Open 24 Hours
8-6 EST SALE SUPPORT
English/Español/Call Us Today
Rare Electrical
Parts for all applications

New 25 Amp 12V Generator For Club Car Golf Carts Ds Series 1984-2006 1018337-01

Replaces Part Numbers & Specifications

CLUB CAR: 101829401 1018337-01 103678502
COLUMBIA PARCAR: 30083-69A 3008369B 30083-69C 3008369D 30083-69E
HITACHI: 3102201HI1 GSB10701 GSB107-01A GSB10704A
HITACHI SALES: GSB107-04C
MANDO: G096503 G338771 M063686
REDHAWK: MOT2002 MOT-2004 MOT2005

ITEM DESCRIPTION: GENERATOR
UNIT TYPE: HITACHI, MANDO, VALEO
VOLTAGE: 12
AMPS: 25
FIELD HSG OD: 113.3MM / 4.461IN
OVERALL LENGTH: 230.3MM / 9.067IN
ROTATION: CW
ROTATION: REVERSIBLE
SHAFT NOTES: THREADED WITH KEYWAY
SHAFT OD: 17MM / 0.669IN
TERMINAL 1 SIZE: M6-1.0
TERMINAL 2 SIZE: M5-0.8
TERMINAL 3 SIZE: M6-1.0
TERMINAL 4 SIZE: M6-1.0
NOTES: 5 TERMINAL MOTOR GENERATOR
WEIGHT: 18.5 LBS / 8.41 KG

Product Notice

As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.



THIS ITEM FITS VARIOUS APPLICATIONS BY PART NUMBER. PLEASE CHECK YOUR PART NUMBER TO ENSURE FITMENT.
CLUB CAR UTV 1998-2002
CLUB CAR GOLF CARTS DS SERIES 1984-2006
EZ-GO GOLF CARTS MEDALIST 2-CYCLE ENGINE 1980-1993
EZ-GO GOLF CARTS PRE-MEDALIST MODELS 1980-1993
TORO EQUIPMENT
