   Brand New!Ultimo Ti SC104 - Morel Ultimo Titanium SC 10" 4 Ohm SC series SubwooferRetail Price: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Features & Specifications: |
Features:
Developed with Morel’s Performance philosophy in mind, the Ultimo Titanium SC delivers innovative engineering, audiophile sound quality and high power output, all at a great consumer value.
The Ultimo Titanium SC subwoofers borrow some of the best technological features from their high-end Ultimo Titanium siblings. This includes the gigantic 5.1” (13mm) Hexatech™ voice coil and titanium former, as well as the beautiful two-layer woven carbon fiber and paper composite cone. A highly efficient magnet motor system with Morel’s DMM (Double Magnet Motor) and EVC design maximizes the magnetic field efficiency, decreases distortion and increases power handling for the most demanding applications. All this is enclosed in an attractive and sleek steel chassis.
With the Ultimato Titanium SC, start experiencing bass as it was meant to sound.
Specifications:
| General Data | Ultimo Titanium SC 10 | |
| Nominal Impedance | 4 Ohm | |
| Overall Dimensions | DxH | 263mm (10.35") x 143 mm (5.63") |
| Power Handling RMS | P | 600W |
| Transient Power 10ms | 2000W | |
| Sensitivity 2.83Vrms/1M | 86dB | |
| Frequency Response | 10-900 Hz | |
| Cone Material | Carbon-fiber laminated paper | |
| Net Weight | 6.1 Kg (13.44 lb) | |
| Driver displacement | 2.34 Lit (0.08 cu.ft) | |
| Voice Coil and Magnet Parameters | ||
| Voice Coil Diameter | 130mm (5.1") | |
| Voice Coil Height | 31mm (1.2") | |
| Voice Coil Former | Titanium | |
| Voice coil wire | Hexatech Aluminum | |
| Number of layers | 2 | |
| Max. Linear excursion | X | ±9.5 mm (0.37")(Each way) |
| Magnet system type | Double magnet vented | |
| HE-Magentic gap height | HE | 12mm (0.47") |
| B flux density | BXL | 0.64 T |
| BL product | BXL | 11 T·M |
| Electrical Data | ||
| Nominal Impedance | Z | 4.0 Ohm |
| DC Resistance | RE | 3.0 Ohm |
| Voice Coil Inductance@ 1KHz | LBM | 1.1 mH |
| T-S Parameters | ||
| Suspension Compliance | CMS | 0.3 mm/N |
| Mechanical Q Factor | QMS | 4.58 |
| Electrical Q Factor | QES | 0.51 |
| Total Q Factor | QTS | 0.46 |
| Mechanical Resistance | RMS | 4.22 N·S/M |
| Moving Mass | MMS | 111.4 g |
| Resonant Frequency | FS | 27 Hz |
| Eq. Cas Air Load (liters) | VAS | 54.6 Lit (1.93 cu.ft) |
| Effective Piston Area | SD | 0.0346 m2 |
