Application

For BMW B58B30 3.0L DOHC Turbocharged Inline‑6 engines
For Toyota GR Supra A90/A91
For BMW G30 540i, G11/G12 740i, G05 X5 xDrive40i,G07 X7 xDrive40i with B58 engine
For BMW G14/G15/G16 840i, G32 640i, and F‑chassis 340i/440i with B58 engine

Specification

Beam Style: H-Beam Street/Strip
Material: 4340 Chromoly Steel
Finish: Shot-peened
Wrist Pin Style: Floating
Clearanced for Stroker: Yes
Cap Retention Style: Through-bolt
Connecting Rod Bolt Brand: ARP
Connecting Rod Bolt Diameter: 3/8"
Connecting Rod Bolt Material: Alloy Steel
Fastener Yield Strength (psi): 220,000 psi (ARP 2000)
Upgrade Fasteners: ARP L19 (260,000 psi) optional
Connecting Rod Bolt Head Style: 12-point
CNC Machined: High Precision
Rod Cap Alignment: Precision dowels
Bore Tolerance: ±0.005 mm
Balancing: ±1 gram per rod
Weight Matched Set: Yes
Remanufactured: No
Testing: Magnafluxed, X-rayed, Ultrasonically tested
Heat Treated: Yes

Dimension

Connecting Rod Length Center to Center: 148.20mm/5.835in
Approximate Connecting Rod Weight: 574g
Big End Bore Diameter: 53.60mm/2.110in
Pin End Bore Diameter: 22.00mm/0.866in
Big End Width: 23.90mm/0.941in
Small End Width: 20.80mm/0.819in

Performance Ratings

Advertised Horsepower Rating: 200HP/piece
Advertised RPM Rating: 9,000rpm

Packaging

Quantity: Sold as a set of 6
Package Size: 28CM*20CM*14CM
