Specification

Condition: 100% Brand New

Product Name: Tire Pressure Monitor Sensors

Fitment Type: Direct Replacement

Quantity: 4 Pieces

Color: Black

Frequency: 315MHz

Package Includes:

• 4pcs Tire Pressure Sensor

Compatibility

Please make sure the interchange part number matches the part you are replacing.Please send us the Make&Model&Year of your vehicle if you can not make sure.We will offer help ASAP.

Optimized Installation Process:

1. Deflate the Tire:
   Remove the valve cap and core to fully deflate the tire.

2. Dismount the Tire:
   Secure the tire onto the tire changer and position the valve at the 1 o’clock position relative to the tire separation head. Use a tire tool to lift the bead over the mounting head and dismount the tire.

3. Remove the Sensor:
   Using a screwdriver, remove the fastening screw and sensor from the valve stem. Then loosen the nut and completely remove the valve.

4. Install the Sensor and Valve:
   Insert the valve stem through the valve hole on the rim. Secure the screw-nut with a torque of 4.0 Nm using a positioning pin for alignment. Attach the sensor body against the rim and tighten the mounting screw.

5. Mount the Tire:
   Position the tire onto the rim, ensuring the valve is oriented 180 degrees opposite the separation head. Carefully seat the tire bead over the rim edge.
