Specialized scopes developed by air rifle shooters, for air rifle shooters!
Airmax scopes use the H2 optics system across a range of models, specifically adapted for the demands of air rifle shooting, and are available with reticles in the first (FFP) and second focal planes (SFP).
The brand-new Airmax 30 WA Touch offers an unparalleled, incredibly wide field of view of 37°. Thanks to the eye relief
of zero, the Airmax 30 WA Touch is ideally suited for pre-charged pneumatic rifles.
Both the AMX and AMX IR reticles are based on 10x Mil-Dot spacing. The AMX reticle offers multiple hold points, especially valuable for air rifles with significant projectile drop.
Half-Mil spacing markings on the lower vertical post provide additional holdover points for longer distances. The other posts are calibrated at 0.5, 1, 1.5, and 2 Mil distances. The hollow posts are marked in Mil increments and can be used for range finding.
| Design | variable magnification |
| Minimum Magnification (x) | 8 |
| Maximum Magnification (x) | 32 |
| Objective Lens Diameter (mm) | 50 |
| Exit Pupil at Min. Magnification (mm) | 6.3 |
| Exit Pupil at Max. Magnification (mm) | 1.6 |
| Eye Relief (mm) | 102 |
| Lens Coating | multi-coated |
| Mounting Type | Mounts not included |
| Main Tube Diameter (mm) | 30 |
| Parallax-Free Range (m) | 9m — 8 |
| Adjustment per Click at 100m | 1/10 MRAD |
| Field of View at Min. Magnification (m) | 20 |
| Field of View at Max. Magnification (m) | 40 |
| Reticle | AMX IR |
| Reticle Plane | Second Focal Plane |
| Reticle Use | Sports Shooting |
| Illuminated Reticle | yes |
| Automatic Shutdown | - |
| Elevation Adjustment | yes (max. 16 MRAD) |
| Windage Adjustment | yes (max. 16 MRAD) |
| Parallax Adjustment | yes |
| Rapid Reticle Adjustment | - |
| Integrated Rangefinder | - |
| Protective Cap | yes |
| Sunshade | yes |
| Waterproof | yes |
| Fogproof | yes |
| Pressure-Waterproof | yes |
| Color | black, matte |
| Length (mm) | 388 |
| Main Tube Length (mm) | 165 |
| Weight (g) | 780 |
| Objective Outer Diameter (mm) | 57 |
| Eyepiece Outer Diameter (mm) | 46 |
| Series | Airmax |
| Stalking | - |
| Ambush | - |
| Driven Hunt | - |
| Magnum Caliber | - |
| Long Range | excellent |
| Air Rifle (< 7.5 Joules) | yes |
| Air Rifle (> 7.5 Joules) | yes |
| Handgun | - |
| Battery Type | CR2032 (1 piece) |
![]() |
![]() |
