| Frame | S-Works Diverge FACT 11r carbon frameset with front and rear Future Shock suspension, SWAT™ Door integration, threaded BB, internal routing, 12x142mm thru-axle, flat-mount disc |
|---|---|
| Fork | Future Shock 2.0 w/ Damper, Smooth Boot, FACT carbon, 12x100 mm thru-axle, flat-mount |
| Wheels | Front: Roval Terra CLX, 25mm internal width, 32mm depth, 21h, Tubeless ready, Roval LFD hub with ceramic SINC bearings, Centerlock disc, DT Swiss Aerolite spokes Rear: Roval Terra CLX, 25mm internal width, 32mm depth, 24h, Tubeless ready, Roval LFD hub with ceramic SINC bearings, Centerlock disc, DT Swiss Aerolite spokes |
| Tires | Tracer Pro 2BR, 700x42 |
| Bottom Bracket | SRAM DUB BSA 68 |
| Crankset | SRAM Red 1 AXS |
| Chainrings | 40T |
| Shifters | SRAM Red eTap AXS |
| Rear Derailleur | SRAM XX1 Eagle AXS |
| Cassette/Freewheel | SRAM XG-1295 Eagle, 12-speed, 10-50t |
| Chain | SRAM XX1 Eagle, 12-speed |
| Brakes | SRAM Red eTap AXS, hydraulic disc, 160mm CenterLine XR rotor |
| Handlebars | Roval Terra, carbon, 103mm drop x 70mm reach x 12º flare |
| Tape/Grips | Supacaz Super Sticky Kush |
| Stem | S-Works Future Stem w/ Integrated Computer mount |
| Seatpost | S-Works Carbon Seat Post, 20mm Offset |
| Saddle | Body Geometry S-Works Power, carbon fiber rails, carbon fiber base |
| Pedals | Sold separately |
| Accessories & Extras | Integrated SWAT door, internal storage system |
