Application:

2015-2017 Polaris RZR 900 Trail EPS
2016 Polaris RZR 900 Trail Fox Edition LE EPS
2016 Polaris RZR 900 Trail Pursuit Camo EPS
2015 Polaris RZR XP 1000 Desert Edition EPS
2014-2018 Polaris RZR XP 1000 EPS
2015 Polaris RZR XP 1000 FOX Edition EPS
2017 Polaris RZR XP 1000 Gold Matte Metallic LE EPS
2015-2018 Polaris RZR XP 1000 High Lifter Edition EPS
2018 Polaris RZR XP 1000 Ride Command Edition EPS
2018 Polaris RZR XP 1000 Trails and Rock Edition EPS
2017 Polaris RZR XP 1000 Veliocity Blue LE EP



If you dont't know the specific of your vehicle, pls confrim by following the below steps:

1) Check Vehicle Bolt Pattern/ PCD

For 4-lug, 6-lug, 8-lug, measure the segment from the center of a bolt hole to the center of another hole.

5-lug is different, you need to measure the segment from the outermost point (not center point) of a bolt hole to the center of another hole.

Take 5 lug for example, if the length of segment as measured in the picture is 5.5"/ 127mm, and as these are 5 lugs, then the bolt pattern is 5.5"/ 127mm.

2) Check Vehicle Hub Bore Size

Measure the diameter of the center bore, make sure the spacer's diameter is the same as or greater than the axle diameter.

3) Check Vehicle Thread Pitch

There are different types of studs, sunch as M14X1.5, M12X1.5, 1/2"x20, 9/16"x18, please make sure the studs of wheel spacers is the same as the vehicle's, otherwise the spacer will not fit.

Measure the fender gap to choose suitable thickness.

Line up a straight edge ruler against the siadewall of the tire, use the measure device to measure from the inside of the ruler to the inner fender lip.

Please take multiple measurements and use the smallest data point (The most closest spot may be at the front or rear edge of the fender). The maximum recommended spacer thickness= the smallest gap - 3/8"(10mm)

Step for Installation Wheel Spacers
