FULL THROTTLE PARTS Nitrous 22A Wide Open Throttle
WOT Dual Throw SPDT Micro Switch & NX Bracket KIT

For Holley 4500/4500HP Dominator, Holley 4500 Generation 3 Dominator
& QFX Series Carburetors

SKU: FTP-15518-22DT





Qty

Part # 		Parts Included in Kit:


1
FTP-15516--4

Universal WOT Switch: SPDT, Normally Open/ Normally Closed (N.O./N.C.) 22 Amp, Brand: Full Throttle Parts
2

Wire Quick Disconnects: Female, 16-14 gauge, fully insulated, blue, .25" spade terminal
1 NX 15518

Switch Mounting Bracket including th3/4" screws, lock washers, washers and nuts to mount the switch. Brand: Nitrous Express





  • Works with any brand nitrous system.
  • Activates nitrous systems, solenoids, fuel pumps, and most anything else.
​

This kit's generic bracket is a universal replacement (generic Holley bracket) for the following billet switch kits: JEGS #16501, Big End Performance #BEP 16210, Nitrous Outlet #16514NOS, and Quick Fuel Technology (QFT) #600-2QFT,

This universal kit works with most EFI vehicles and includes a double throw, 22 amp, micro limit switch and bracket with mounting hardware.


It's designed to trigger a relay at or near wide open throttle. Can also be used to activate solenoids, fuel pumps and most anything else.

This micro switch that has 3-poles so you can also use the additional pole for timing retard or another function that you want activated at wide open throttle. It features both a normally closed and a normally open switch.


The mounting bracket is aluminum and is approximately 2 38/64" long and approx. 4/64" or approx 1.5875mm thick.

Installation instructions are included.



Product Specifications:
Kit SKU FTP-15518-22DT
Controls Nitrous systems, Solenoids, Fuel Pumps, etc.
Bracket Material Aluminum
Bracket SKU NX-15518-DOM
Switch Type 22A, Normally Open/Normally Closed, SPDT micro switch
Switch SKU FTP-V15H22-22DT
Adjustable Switch lever can be bent or trimmed
Free Returns Yes
Returns 30 days

*Is a suitable WOT switch replacement unless you are using a 25 amp switch.

















All Fitments
UNIVERSAL
Year Model Cylinders Eng Desg. Fuel
0 - 0 Universal for DOMINATOR 4500 or QFX Series Carburetors. APPLICATION SPECIFIC. ALL ALL ALL

All switches tested for continuity.
