Optical Tube Info | |
|---|---|
| Optical Design | Schmidt-Cassegrain |
| Aperture | 150mm (5.91") |
| Focal Length | 1500mm (59") |
| Focal Ratio | f/10 |
| Focal Length of Eyepiece 1 | 25mm (.98") |
| Magnification of Eyepiece 1 | 60x |
| Finderscope | StarPointer™ red dot finderscope |
| Star Diagonal | 1.25" Star Diagonal |
| Optical Tube | Aluminum |
| Highest Useful Magnification | 354x |
| Lowest Useful Magnification | 21x |
| Limiting Stellar Magnitude | 13.4 |
| Resolution (Rayleigh) | 0.93 arc seconds |
| Resolution (Dawes) | 0.77 arc seconds |
| Light Gathering Power (Compared to human eye) | 459x |
| Secondary Mirror Obstruction | 56mm (2.2") |
| Secondary Mirror Obstruction by Diameter | 37% |
| Secondary Mirror Obstruction by Area | 14% |
| Optical Coatings | StarBright XLT |
| Optical Tube Length | 406mm (16") |
| Optical Tube Diameter | 181mm (7.1") |
| Optical Tube Weight | 8 lbs (3.6 kg) |
Mount Info | |
| Mount Type | Computerized Altitude-Azimuth Single Fork Arm |
| Instrument load capacity | 12 lbs (5.44 kg) |
| Height adjustment range (includes mount and tripod) | 965.2mm - 1422.4mm (38" - 56") |
| Tripod leg diameter | 50.8mm (2") Stainless Steel |
| Mount Head Weight | 11 lbs (5 kg) |
| Accessory Tray | Yes |
| Tripod Weight | 9 lbs (4.08 kg) |
| Slew Speeds | 9 slew speeds - max speed 5°/second |
| Tracking Rates | Sidereal, Solar and Lunar |
| Tracking Modes | Alt-Az, EQ North & EQ South |
| GPS | N/A |
| Dovetail Compatibility | CG-5 dovetail |
| Number of Auxiliary ports | 1x Aux port |
| Autoguide port | Yes |
| USB port | Yes, Hand Control input |
| Power Requirements | 8-AA batteries (not included) | 12 VDC-750 mA (Tip positive) |
| Motor Drive | DC servo motors |
| Alignment Procedures | SkyAlign, 1-Star Align, 2-Star Align, Auto 2-Star Align, Solar System Align, EQ North / EQ South Alignment (EQ align requires an equatorial wedge) |
| Periodic Error Correction | No |
| Computerized Hand Control | Double line, 18 character Liquid Crystal Display with 19 fiber optic backlit LED buttons |
| NexStar+ Database | 40,000 objects, 200 user defined programmable objects. Enhanced information on over 200 objects |
| Software | Celestron's Starry Night Special Edition Software, SkyPortal App |
| Total Kit Weight | 21 lbs (9.5 kg) |
In the Box | |
| Included Items | NexStar SE OTA | Single Fork Arm Mount | Tripod | Accessory Tray | Star Pointer Finderscope | NexStar+ Hand Control | 25mm eyepiece | Star Diagonal |
