Features
1. Embedded Linux System, stable and effective.
2. Friendly Web Control UI, default IP is 192.168.1.168. user name and password both are admin.
3. H.264/H.265-encoded stream Support RTMP, RTSP, UDP, HTTP, HLS, FLV and ONVIF Protocols. you can choose any of the popular streaming platforms to go live at anytime you like , such as Ustream, Livestream, Facebook Live, and YouTube Live or even build your own using Wowza Streaming Server .
4. Support multi-stream,one main stream and three sub-stream, up max to 4 stream at the same time.you can push multi-platform in the meantime.
5.The main SOC chip’s Video Encoding Performance is:
A maximum of 5-megapixel resolution for H.264/H.265 encoding
Real-time H.264/H.265 encoding of multiple streams:
-1080p@30 fps+720p@30 fps+VGA@30 fps
-1080p@60 fps+VGA@30 fps
-5-megapixel@30 fps+VGA@30 fps
JPEG snapshot at 5-megapixel@8 fps
Supporting the CBR/VBR bit rate control mode, ranging from 16 kbit/s to 40 Mbit/s
Encoding frame rate ranging from 1/16 fps to 240 fps
Encoding of eight ROIs
6. Main Stream Support output resolution - 1920x1080, 1680x1056, 1280x720, 1024x576, 850x480, 720x576, 720x540, 720x480, 720x404, 704x576, 640x480, 640x360, 608x448, 544x480, 480x480, 480x384, 480x360, 480x320, 480x272, 480x270, 400x320, 400x224, 352x480, 352x228, 320x256, 320x240, 320x180, 240x180, 176x144.
7. Support Text and BMP photo insert as Stream Logo for main stream & 2nd stream.
8. Output Stream bitrate adjustable.
9. Support firmware upgrade.
10. IP address can be set by yourself.
11. Support remote control via router port forward.
Application
1. IPTV
2. Online Live Broadcast
3. NVR (Net Video Recorder)
4. Teaching / Campus Broadcast
5. Hotel TV system
6. Video Conference
7. Digital Signage
8. Recording System
Usages:
You can play the video directly using some software tools like vlc or potplayer etc, for example,
1) http://192.168.1.168/0.ts
Usages:
You can play the video directly using some software tools like vlc or potplayer etc, for example,
1) http://192.168.1.168/0.ts
2) http://192.168.1.168/0.hls
3) http://192.168.1.168/0.m3u8
4) http://192.168.1.168/0.flv
5) rtsp://192.168.1.168/0
6) udp://@238.0.0.1:1234
also,set the RTMP push address from the third live webcasting platform, such as YouTube, Ustream, Twitter, Sopplus, etc.
Specifications
| Video | |
Input | 1 * SDI (HD-SDI and 3G-SDI Support) |
Supports input HD-SDI Resolution | Max support 1920x1080P@60Hz |
Output Stream Resolution | Max support 1920x1080P@60Hz |
Data Rate | 0.1Mbps~32Mbps |
Rate Control | CBR / VBR |
GOP Structure | IBBP |
Advanced Pretreatment | De-interlacing, Noise Reduction, Sharpening |
| Audio | |
Encoding | AAC |
Sampling rate | Auto |
Bit-rate | 48K/64K/96K/128K/160K/192K |
Sampling precision | 24 bit |
Data Rate | 64Kb/s~384Kb/s |
| System | |
Ethernet | 100Base-T Ethernet interface |
Protocol | RTMP, RTSP, UDP,HTTP,HLS, FLV ONVIF |
User Interface | WEB default IP - http://192.168.1.168/index.html |
| Others | |
Dimension (W* L*H) | 165*130*30mm |
Weight | 0.3kg |
Power | 12V/DC |
Consumption | 5W |
