Description:
- 100% brand new and high quality
- Material: Electrical components
- Color: See pictures
- 42/57/86 TB6600 Stepper Motor 32-segment
driver updated version 4.0A 40VDC for CNC milling machine
- Specifications:
- This unit is an upgraded version of TB6600,
the breakdown of increase to 32 segments, for high targeting purposes.
Applicable stepper motor: 42.57, 86 Phase type phase (4 wire 6 wire 8 wire line)
- Characteristics:
- 1, 9 V-40 V DC power supply;
- 2, H-bridge Bipolar constant-phase
flow-driven;
- 3, the maximum output current of 4.0A eight
optional;
- 4, up to 32 segments of six types of sub-modes
available;
- 5, the input signal is high-speed optical
insulation;
- 6, standard common anode single pulse
interface;
- 7, HOLD function offline;
- 8, semi-closed chassis can accommodate the
most demanding environment;
- 9, provide semi-automatic current locking
function;
- 10, built-in thermal protection and
overcurrent protection.
- Size: 9.6*5.5*2.7cm/3.88"*2.17"*1.06"
- Quantity: 1Pc
- Note: Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you!
Package includes:
- 1Pc x TB6600 Single Axis 4A Stepper Motor
Driver Controller 9~40V Micro-Step CNC
|
