*Three axes control; 5 axes linkage; 2 analog spindles

*ms interpolation cycle, 0.1μm control precision.

*wo channels -10V ~ 10V analog voltage output, support double spindle control

*Linear type, index type and S type etc. acceleration and deceleration types can be chosen.

*Embedded with PLC programming, the current running PLC programming can be chosen

*PLC displayed online, real time monitoring, signal real time tracing

*Supports statement type macro programming, supports macro codes with parameters calls.

*Flexible tapping and rigid tapping can be set by parameters

*Includes spiral, scaling, polar coordinate, fixed circle and a variety of slotting compound cycle function.

*Includes historical alarm and resumen operation functions, it’s convenient for users to operate and maintenance.

*Support multi-level passwords for equipment maintenance and management

*36 point general input/36 point general output

*Support standard RS232 and USB port, support U disk documents operation, system configuration and software

 updated, it can meet the functions that documents transfer, serial ports DNC machining and USB online machining

Display interface:

*7.0 inch wide-screen LCD, 800×480 lattice

*Chinese, English etc multiply language display

*2D tool path displays.

*Real-time clock

Operation mode:

*Operation modes: edit, automatic, input, machine tool reset, handwheel/single-step, manual, DNC.

*Multiple operateauthority management.

*Alarm logging

Program edit:

*Program volumn: 56MB, it can store 400 programmings mostly (includes sub-programming, Marco programming)

*Edit function: Programming/programming segment/word retrieval, amend, delete, copy, and stick

*Programming format: ISO code,supports statement macro program, supports relative coordinate, absolute

   coordinate and polar coordinate.

*Programming calls: supports maco with parameters calls, level 4 subprogram nesting.

Communication function:

*RS232: parts program, parameters and some documentation two-way transmission, supports PLC program, system

   software serial ports update.

*USB: U disk documentation operatiom, U disk processing directly, Support PLC program, system software U disk

   update.

*Support serial port DNC processing function and USB online processing function, reliability and safty

   Relability and safty function

*Emergency stop

*Handware route limit

*Software routet inspect

*Data backups and Data recover.

​
