• Circuit control: 12V step-down circuit, constant current output (current and voltage are adjustable)

• Output Specifications: Max 5A

• Scope of application: 15W blue laser drive circuit

• Dimensions: 46*80mm (width * length), component height with aluminum base 26m

• Modulation voltage: 0-5V (0V off, 5V on)

• TTL modulation description: 0-5V voltage signal (0 is off, 5 is on, frequency determines the speed of laser light flashing), positive and negative as shown below



1*15W laser driver

1* laser cable
