Pals notice: These DIY kits not soldered

If need data. We will sent you email

Highest real-time sampling rate: 1Msps

Accuracy: 12Bit

Sampling buffer depth: 1024 bytes

Analog bandwidth: 0 - 200 KHz

Vertical sensitivity: 10mV / Div. - 5V / Div. (1-2-5 progressive manner)

Adjustable vertical displacement, and with instructions

Input impedance: 1MΩ

Maximum input voltage: 50Vpp (1: 1 probe), 400Vpp (10: 1 probe)

Coupling modes include DC / AC / GND

 Horizontal time base range: 10μs / Div. - 50s / Div. (1-2-5 progressive manner)

With automatic, conventional and single -shot mode, easy waveform capture the moment

Available rising or falling edge trigger

Adjustable trigger level position, and with instructions

Observable trigger waveform before (negative delay)

Can always freeze the waveform display (HOLD function)

Comes 1Hz /3.3V square wave test signal source
